The 1756-M12 ControlLogix Motion Module from Rockwell Automation is a specialized industrial multi-axis motion control module designed for advanced servo applications requiring precise synchronization, fast response times, and seamless integration within the ControlLogix automation platform.
Engineered for demanding industrial environments, the 1756-M12 delivers reliable coordinated motion control for high-speed manufacturing systems, packaging machinery, robotics, and automated assembly lines. Its modular architecture allows machine builders and system integrators to create scalable motion systems with excellent real-time performance.
Technical Specifications (Including Size & Weight)
| Parameter | Specification |
|---|---|
| Model | 1756-M12 |
| Series | ControlLogix Motion Modules |
| Module Type | Multi-Axis Motion Control Module |
| Motion Capability | Coordinated servo motion control |
| Communication Interface | ControlLogix backplane integration |
| Supported Applications | Position, velocity, and torque control |
| Encoder Support | Incremental encoder feedback |
| Synchronization | Multi-axis coordinated motion |
| Update Rate | High-speed deterministic processing |
| Backplane Current (5.1V DC) | ~800 mA |
| Power Dissipation | ~6 W |
| Isolation | Industrial-grade isolation protection |
| Compatibility | ControlLogix chassis systems |
| Programming Software | Studio 5000 / RSLogix 5000 |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -40°C to 85°C |
| Humidity | 5%–95% non-condensing |
| Mounting | Standard ControlLogix slot installation |
| Weight | ~0.40–0.75 kg |
Physical Dimensions
- Size (H × W × D): 145 × 35 × 140 mm
The compact single-slot design helps optimize cabinet space while maintaining strong motion processing capability for industrial automation systems.
Recommended Related Models
The 1756-M12 is commonly integrated with:
- 1756-L71 / 1756-L73 ControlLogix CPUs
- 1756-M03SE SERCOS motion modules
- 1756-M08SE 8-axis servo modules
- Kinetix servo drive systems
- 1756-EN2T EtherNet/IP communication modules
Popular Allen-Bradley Motion Control Models
Within the ControlLogix motion ecosystem, widely used modules include:
- 1756-M03SE SERCOS servo module
- 1756-M08SE multi-axis motion module
- 1756-M02AE analog motion controller
- 1756-HYD02 hydraulic motion module
- Kinetix integrated motion platforms
These solutions support scalable architectures for precision industrial motion control applications.
