Brand:Allen Bradley PLC Item No.:Allen Bradley 1762-OW16 Product Origin:USA Product Dimensions:90 x 87 x 40 mm Product Weight:0.36 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Allen Bradley 1762-OW16 Relay Output Module is designed to deliver dependable relay-based output control for industrial automation systems requiring flexible switching capability and stable long-term performance. As part of the widely trusted MicroLogix expansion I/O platform, this module offers efficient signal management for applications involving mixed voltage loads and industrial field devices.
With 16 relay outputs integrated into a compact industrial housing, the 1762-OW16 provides excellent adaptability for machine builders, system integrators, and manufacturing facilities seeking scalable control expansion without sacrificing cabinet space or operational reliability.
Product Specifications Overview
Specification Category
Technical Details
Brand
Allen Bradley
Model Number
1762-OW16
Module Type
Relay Output Module
Product Series
MicroLogix 1200 Expansion I/O
Number of Outputs
16 Relay Outputs
Output Contact Type
Normally Open Relay
Voltage Range
5 to 265V AC / 5 to 125V DC
Maximum Current per Output
2.5 A
Isolation
Relay Isolated Outputs
Response Time
Approx. 10 ms
Mounting Style
DIN Rail / Panel Mount
Diagnostic Indicators
Integrated LED Status Indicators
Operating Temperature
0°C to 55°C
Storage Temperature
-40°C to 85°C
Environmental Humidity
5% to 95% Non-Condensing
Dimensions
Approx. 90 x 87 x 40 mm
Weight
Approx. 0.36 kg
Recommended Compatible Models
Related Model
Product Function
1762-L40BWAR
MicroLogix CPU Controller
1762-IQ16
Digital Input Module
1762-OB8
DC Transistor Output Module
1762-IF4
Analog Input Expansion
1762-OF4
Analog Output Module
1761-CBL-PM02
PLC Programming Cable
Popular Allen Bradley Industrial Products
Model Number
Product Category
1756-L73
ControlLogix Processor
1769-L30ER
CompactLogix Controller
1734-OW4
POINT I/O Relay Output Module
5069-OB16F
Compact 5000 Output Module
2711P-T15C22D9P
PanelView Plus HMI
1783-US8T
Industrial Ethernet Switch
Industrial Application Areas
The Allen Bradley 1762-OW16 Relay Output Module is commonly deployed in industrial systems that require flexible relay switching for various electrical loads and control devices.
Typical application environments include:
Conveyor automation systems
Industrial packaging equipment
Pump and motor control systems
Material handling machinery
Building automation systems
HVAC control panels
Food and beverage production lines
Water treatment automation
Its relay-based architecture allows it to manage both AC and DC loads, making it highly versatile across different automation scenarios.
Product Advantages
Flexible Relay Switching Capability
The module supports a broad voltage range, allowing reliable control of multiple device types within industrial automation systems.
High-Density Output Expansion
With 16 relay outputs in a compact structure, the 1762-OW16 helps reduce cabinet space usage while increasing control capacity.
Industrial-Grade Reliability
Designed for continuous operation, the module provides stable long-term performance in demanding industrial environments.
Easy Integration with MicroLogix Systems
The module installs seamlessly into compatible MicroLogix architectures, simplifying expansion and reducing engineering effort.
Simplified Diagnostics and Maintenance
Built-in LED indicators provide fast visual monitoring of output status, helping maintenance personnel reduce troubleshooting time.
Technical FAQs
1. What is the primary function of the 1762-OW16 module?
The module provides 16 relay outputs for industrial automation system expansion.
2. What type of outputs does the module use?
It uses relay-based outputs suitable for both AC and DC load switching applications.
3. How many outputs are available?
The module includes 16 relay output channels.
4. Is the 1762-OW16 compatible with MicroLogix systems?
Yes. It is designed for integration with Allen Bradley MicroLogix controllers and expansion systems.
5. Can the module control different voltage loads?
Yes. The relay outputs support a wide operating voltage range for flexible industrial control.
6. What installation methods are supported?
The module supports DIN rail mounting and direct panel installation.
7. Is the module suitable for industrial environments?
Yes. It is engineered for continuous-duty industrial automation applications.
8. Does the module include diagnostic indicators?
Yes. LED status indicators are integrated for output monitoring and troubleshooting support.
9. What industries commonly use the 1762-OW16?
It is widely used in manufacturing, logistics, water treatment, HVAC, and packaging industries.
10. Why is the 1762-OW16 popular in industrial automation projects?
Its flexible relay outputs, compact structure, reliable operation, and easy system integration make it a trusted expansion solution for industrial control systems.
