Brand:Allen Bradley PLC Item No.:Allen Bradley 1763-L16DWD Product Origin:USA Product Dimensions:90 × 87 × 110 mm Product Weight:2.0 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Allen Bradley 1763-L16DWD is a compact MicroLogix 1100 programmable logic controller (PLC) designed for small to mid-scale industrial automation systems requiring integrated control, communication, and flexible I/O handling. It combines onboard digital inputs, analog inputs, and relay outputs in a single controller, making it a space-efficient and cost-effective solution for machine-level automation.
Built with Ethernet communication capability and an LCD interface, the 1763-L16DWD is widely used in OEM equipment, packaging machines, and process control systems where real-time monitoring and reliable control execution are essential.
Technical Specifications
Specification Item
Details
Product Brand
Allen Bradley
Model Number
1763-L16DWD
Product Type
MicroLogix 1100 CPU Module
Power Supply
120–240V AC / 12–24V DC (system dependent configuration)
Digital Inputs
10 total (standard + high-speed inputs)
Analog Inputs
2 × 0–10V DC
Digital Outputs
6 Relay Outputs
Communication Ports
Ethernet, RS-232 / RS-485
Programming Memory
Approx. 8 KB
Display
Built-in LCD interface
Input Voltage Range
12/24V DC input signal level
Output Type
Relay contact outputs
Operating Temperature
-20°C to 65°C
Storage Temperature
-40°C to 85°C
Mounting Type
DIN rail / panel mount
Dimensions
Approx. 90 × 87 × 110 mm
Weight
Approx. 0.6–2.0 kg (varies by configuration)
Recommended Related Models
Related Model
Function
1762-IQ16
Digital input expansion module
1762-OB8
DC transistor output module
1762-OW16
Relay output expansion module
1762-IF4
Analog input module
1762-OF4
Analog output module
1761-CBL-PM02
Programming cable
Popular Allen Bradley Automation Products
Model
Category
1756-L81E
ControlLogix CPU
1769-L33ER
CompactLogix controller
5069-IF8
Analog input module
1734-OB8
POINT I/O output module
2711P-T10C4D8
PanelView HMI terminal
1783-US5T
Industrial Ethernet switch
Industrial Applications
The 1763-L16DWD is widely used in compact automation systems where integrated control and communication are required in a single device.
Typical applications include:
Packaging and labeling machines
Small-scale production lines
Pump and compressor control systems
HVAC automation systems
Conveyor control systems
Water treatment subsystems
OEM machine control panels
Simple process automation tasks
Its built-in Ethernet capability makes it especially useful for remote monitoring and basic SCADA integration.
Key Advantages
Integrated All-in-One Design
Combines CPU, I/O, and communication in a single compact unit, reducing wiring complexity and cabinet space requirements.
Built-in Ethernet Communication
Supports modern industrial networking, enabling easier system integration and remote diagnostics.
Flexible Mixed I/O Capability
Onboard digital, analog, and relay I/O allow direct control of diverse field devices without external modules.
Reliable Industrial Performance
Designed for stable operation in harsh industrial environments with long service life and strong electrical noise immunity.
Cost-Effective Automation Solution
Reduces the need for multiple modules, helping lower overall system cost while maintaining dependable performance.
Technical FAQs
1. What is the 1763-L16DWD used for?
It is a MicroLogix 1100 PLC used for small to medium industrial automation and machine control.
2. Does it include built-in I/O?
Yes. It includes digital inputs, analog inputs, and relay outputs integrated into the CPU.
3. Does the controller support Ethernet communication?
Yes. It includes built-in Ethernet for industrial networking and remote access.
4. What type of outputs does it use?
It uses relay outputs suitable for AC and DC load switching.
5. How many analog inputs are available?
It includes 2 analog inputs supporting 0–10V DC signals.
6. Is it suitable for OEM machine builders?
Yes. Its compact all-in-one design makes it ideal for OEM equipment integration.
7. What programming environment is used?
It is typically programmed using RSLogix 500 software.
8. Can it be used in harsh environments?
Yes. It is designed for industrial temperature ranges and electrical noise resistance.
9. Is the model still in production?
No. It has been officially discontinued by the manufacturer but is still widely used in legacy systems.
10. Why is the 1763-L16DWD still popular?
Because it offers integrated control, Ethernet connectivity, and compact design, making it reliable for maintaining and upgrading existing MicroLogix-based systems.
