Brand:Allen Bradley PLC Item No.:Allen Bradley 1766-L32BXBA Product Origin:USA Product Dimensions:87 × 180 × 90 mm Product Weight:2.0 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Allen Bradley 1766-L32BXBA is a high-capability MicroLogix 1400 programmable logic controller designed for industrial automation systems requiring integrated analog I/O, high-speed digital processing, and multi-protocol communication in a compact PLC platform. It is widely used in OEM machinery, process automation, and retrofit projects where Ethernet connectivity and flexible signal handling are essential.
This model represents one of the more feature-rich configurations in the MicroLogix 1400 series, combining digital inputs, relay outputs, fast DC outputs, and embedded analog channels into a single controller. Its strong communication capabilities and expanded I/O structure make it suitable for complex machine-level control and networked industrial systems.
High-speed counters and pulse outputs (application dependent)
Expansion Support
Up to 7 MicroLogix expansion modules
Programming Software
RSLogix 500
Operating Temperature
-20°C to 60°C
Storage Temperature
-40°C to 85°C
Mounting Type
DIN rail / panel mount
Dimensions
Approx. 87 × 180 × 90 mm
Weight
Approx. 1.0–2.0 kg
Recommended Related Models
Related Model
Function
1766-L32BWAA
Ethernet-enabled MicroLogix 1400 variant
1766-L32BWA
Standard MicroLogix 1400 CPU
1766-L24AWA
Compact MicroLogix 1400 controller
1762-IF4
Analog input expansion module
1762-OB8
DC transistor output module
1762-OW16
Relay output module
Popular Allen Bradley Automation Products
Model
Category
1756-L81E
ControlLogix processor
1769-L33ER
CompactLogix controller
1734-IB8
POINT I/O input module
5069-OF4
Analog output module
2711P-T10C4D8
PanelView HMI terminal
1783-US8T
Industrial Ethernet switch
Industrial Applications
The 1766-L32BXBA is widely used in industrial environments where high-speed control, analog processing, and multi-network communication are required within a single PLC system.
Typical applications include:
High-speed packaging and sorting machinery
Conveyor synchronization and motion-adjacent control
Printing and labeling systems
Process control and batching systems
Water and wastewater treatment plants
HVAC and energy management systems
OEM machine automation platforms
SCADA-connected industrial networks
Its combination of fast digital I/O and embedded analog channels makes it especially suitable for mixed-signal automation environments.
Key Advantages
High-Speed Mixed I/O Architecture
Combines high-speed digital inputs with relay and fast DC outputs, enabling precise timing control and flexible machine logic execution.
Integrated Analog Processing
Built-in analog inputs and outputs eliminate the need for external analog modules in smaller control systems.
Strong Industrial Networking Capability
Supports Ethernet and serial communication protocols for seamless integration with SCADA, HMI, and industrial networks.
Compact All-in-One PLC Design
Reduces cabinet space and wiring complexity by integrating CPU, I/O, and communication into one controller.
Reliable Legacy System Performance
Designed for long-term operation in established industrial environments with strong durability and stable control execution.
Technical FAQs
1. What is the 1766-L32BXBA used for?
It is a MicroLogix 1400 PLC used for industrial automation, machine control, and process monitoring with integrated analog and high-speed I/O.
2. Does it include analog I/O?
Yes. It includes 4 analog inputs and 2 analog outputs.
3. What types of outputs does it support?
It supports relay outputs, fast DC transistor outputs, and standard DC outputs.
4. Does it support Ethernet communication?
Yes. It includes a built-in Ethernet port for industrial networking.
5. What programming software is required?
It is programmed using RSLogix 500 software.
6. How many I/O points does it have?
It includes 20 digital inputs and 12 digital outputs, plus analog channels.
7. Can it be used in SCADA systems?
Yes. It supports multiple industrial protocols including EtherNet/IP and Modbus.
8. Is it suitable for high-speed applications?
Yes. It supports high-speed counters and fast digital outputs depending on configuration.
9. Is it still in production?
It is classified as a mature product but remains widely used in existing industrial installations.
10. Why is the 1766-L32BXBA still popular?
Because it combines high-speed I/O, analog capability, and strong networking in a compact PLC platform that continues to support long-life industrial automation systems.
