Brand:Allen Bradley PLC Item No.:Allen Bradley 1769-IF8 Product Origin:USA Product Dimensions:118 × 35 × 87 mm Product Weight:0.32 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Allen Bradley 1769-IF8 is a high-density analog input module designed for CompactLogix and MicroLogix control platforms that require accurate multi-channel analog signal acquisition in a compact footprint. As part of the Compact I/O family, this module delivers reliable process monitoring, flexible signal compatibility, and scalable expansion capability for modern industrial automation environments.
With eight individually configurable analog input channels, the 1769-IF8 enables efficient integration of sensors, transmitters, and process instrumentation into centralized control architectures. Its high-resolution analog conversion and dependable industrial performance make it a trusted solution for demanding process control applications.
Technical Specifications
Specification Item
Details
Manufacturer
Allen Bradley (Rockwell Automation)
Model Number
1769-IF8
Product Type
Analog Input Module
Product Family
Compact I/O Series
Number of Channels
8 Analog Inputs
Input Signal Types
Voltage / Current
Supported Voltage Ranges
±10V DC, 0–10V DC, 0–5V DC, 1–5V DC
Supported Current Ranges
0–20 mA, 4–20 mA
Resolution
16-bit
Converter Type
Delta-Sigma
Channel Configuration
Individually configurable
Backplane Current Draw
Approx. 220 mA @ 5V DC
Power Dissipation
Approx. 5.5 W
Isolation
Channel-to-system isolation
Data Update Rate
Configurable per channel
Diagnostic Features
Over-range / under-range detection
Status Indicators
LED module diagnostics
Wiring Configuration
Differential or single-ended
Operating Temperature
0°C to 60°C
Storage Temperature
-40°C to 85°C
Mounting Type
DIN rail / panel mount
Dimensions
Approx. 118 × 35 × 87 mm
Weight
Approx. 0.32 kg
Recommended Related Models
Related Model
Function
1769-IF4
4-channel analog input module
1769-OF8C
Analog output module
1769-IF4I
Isolated analog input module
1769-L33ER
CompactLogix controller
1768-ENBT
Ethernet communication module
1769-OB16
Digital output module
Popular Allen Bradley Automation Products
Model
Category
1756-L81E
ControlLogix processor
5069-IF8
Compact 5000 analog module
1734-IE8C
POINT I/O analog module
2711P-T10C4D8
PanelView Plus HMI
1783-US8T
Industrial Ethernet switch
1606-XLE240E
Industrial power supply
Industrial Applications
The 1769-IF8 is widely deployed in industrial systems requiring high-density analog signal acquisition and precise process monitoring.
Typical applications include:
Process automation and instrumentation systems
Temperature and pressure monitoring networks
Water and wastewater treatment facilities
Chemical and pharmaceutical processing
HVAC and environmental control systems
Energy management applications
OEM skid-mounted process equipment
Industrial sensor integration platforms
Its 8-channel design allows multiple f
Key Advantages
High-Density Analog Acquisition
Supports eight analog input channels in a compact module, maximizing I/O capacity while reducing panel space usage.
High-Precision Signal Processing
The 16-bit analog conversion delivers accurate measurement performance for demanding industrial applications.
Flexible Input Compatibility
Supports both voltage and current signals, simplifying integration with a wide range of industrial transmitters and sensors.
Scalable Compact I/O Architecture
Integrates seamlessly into CompactLogix systems, allowing flexible expansion as automation requirements grow.
Reliable Industrial Durability
Designed for continuous operation in harsh industrial environments with strong resistance to electrical interference.
Technical FAQs
1. What is the 1769-IF8 used for?
It is an analog input module used to collect and process analog signals from industrial field devices.
2. How many analog channels does it provide?
The module provides 8 analog input channels.
3. What signal types are supported?
It supports both voltage and current analog input signals.
4. What is the resolution of the module?
The module provides 16-bit analog resolution.
5. Is it compatible with CompactLogix systems?
Yes. It is designed for CompactLogix and Compact I/O automation platforms.
6. Can it support 4–20 mA transmitters?
Yes. It fully supports standard industrial 4–20 mA current-loop devices.
7. Are the channels individually configurable?
Yes. Each channel can be configured independently through software settings.
8. What mounting methods are supported?
The module supports DIN rail and panel mounting installations.
9. Is it suitable for process control systems?
Yes. It is widely used in process automation and industrial monitoring applications.
10. Why is the 1769-IF8 widely used in industrial automation?
Because it combines high channel density, accurate analog conversion, flexible signal support, and reliable integration into Allen Bradley CompactLogix systems.
