Allen Bradley 1769-L16ER-BB1B CompactLogix Controller
Allen Bradley 1769-L16ER-BB1B CompactLogix Controller
0.0
Points
Brand:Allen Bradley PLC Item No.:Allen Bradley 1769-L16ER-BB1B Product Origin:USA Product Dimensions:130 × 100 × 105 mm Product Weight:0.7 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Allen Bradley 1769-L16ER-BB1B is a CompactLogix 5370 L1 programmable automation controller designed for small to mid-size industrial applications that require built-in I/O, dual Ethernet communication, and compact system architecture. It combines a processor, embedded digital I/O, and communication capabilities into a single integrated platform, making it a cost-effective and space-saving solution for OEM machine control and factory automation systems.
This controller is widely used in applications where simplicity, reliability, and Ethernet-based connectivity are essential, while still maintaining scalability through POINT I/O expansion.
Expanded CompactLogix controller with more features
1734-IB8
POINT I/O DC input module
1734-OB8
POINT I/O DC output module
1769-IQ16
Compact DC input module expansion
1769-IF8
Analog input module
Popular Allen Bradley Automation Products
Model
Category
1756-L8x Series
ControlLogix controllers
5069-L3xER Series
Compact 5000 controllers
1734 POINT I/O Series
Distributed I/O modules
2711P PanelView Plus
HMI operator panels
1783 Ethernet Switches
Industrial networking
1606 Power Supplies
Industrial DC power systems
Industrial Applications
The 1769-L16ER-BB1B is widely used in compact automation systems where integrated control and Ethernet communication are essential.
Typical applications include:
OEM machine automation systems
Conveyor and material handling systems
Packaging machinery and labeling equipment
Small production line control systems
HVAC and building automation
Pump and motor control systems
Factory test and inspection equipment
Distributed small-scale industrial systems
Its built-in I/O and Ethernet capability make it particularly effective for standalone machines that still require network connectivity.
Key Advantages
All-in-One Compact Design
Integrates CPU, digital I/O, and communication in one unit, reducing panel space and wiring complexity.
Dual Ethernet Ports with DLR Support
Enables flexible network topologies including Device Level Ring for enhanced network resilience.
Scalable I/O Expansion
Supports POINT I/O modules, allowing gradual system expansion without replacing the controller.
Simplified Machine Architecture
Reduces the need for separate remote I/O racks and communication modules in small automation systems.
Industrial-Grade Reliability
Built for continuous operation in harsh industrial environments with stable performance and strong diagnostics.
Technical FAQs
1. What is the 1769-L16ER-BB1B used for?
It is a CompactLogix PLC used for controlling small to mid-size industrial automation systems.
2. Does it include built-in I/O?
Yes. It includes 16 DC inputs and 16 DC outputs integrated into the controller.
3. What software is used to program it?
It is programmed using Studio 5000 Logix Designer.
4. How many Ethernet devices can it support?
It supports up to 4 Ethernet/IP nodes depending on configuration.
5. Can it be expanded with additional I/O?
Yes. It supports up to 6 POINT I/O modules (1734 series).
6. Does it support modern industrial networks?
Yes. It supports EtherNet/IP and Device Level Ring (DLR) topologies.
7. What is the memory capacity?
It has approximately 384 KB of user memory.
8. Is it suitable for OEM machines?
Yes. It is widely used in OEM equipment due to its compact all-in-one design.
9. What is its power supply requirement?
It operates on 24V DC industrial power.
10. Why is the 1769-L16ER-BB1B popular in automation?
Because it combines PLC processing, built-in I/O, Ethernet connectivity, and expansion flexibility in a compact and cost-efficient platform for machine control systems.
