Allen Bradley 1769-L36ERM CompactLogix Motion Controller
Allen Bradley 1769-L36ERM CompactLogix Motion Controller
0.0
Points
Brand:Allen Bradley PLC Item No.:Allen Bradley 1769-L36ERM Product Origin:USA Product Dimensions:145 × 118 × 87 mm Product Weight:1.1 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Allen Bradley 1769-L36ERM is a CompactLogix 5370 L3 motion controller built for advanced automation environments that require high-speed processing, integrated motion control, and reliable industrial Ethernet communication. Designed for coordinated multi-axis applications, this controller combines powerful Logix processing with CIP Motion support and scalable Compact I/O expansion.
Widely deployed in sophisticated OEM machinery and high-performance production systems, the 1769-L36ERM delivers outstanding synchronization, deterministic communication, and machine-level precision for modern industrial automation.
Technical Specifications
Specification Item
Details
Manufacturer
Allen Bradley (Rockwell Automation)
Model Number
1769-L36ERM
Product Family
CompactLogix 5370 L3 Motion Series
Controller Type
Motion Programmable Automation Controller (PAC)
User Memory
3 MB
Motion Axes Supported
Up to 16 CIP Motion axes
Communication Ports
2 × EtherNet/IP ports, 1 × USB
Ethernet Features
Embedded switch, Device Level Ring (DLR)
Motion Protocol
CIP Motion over EtherNet/IP
Network Topologies
Linear, star, DLR
EtherNet/IP Nodes
Up to 48 nodes
TCP Connections
Up to 256
I/O Expansion Capacity
Up to 30 Compact I/O modules
Expansion Banks
Multiple bank architecture supported
Programming Software
Studio 5000 Logix Designer
Data Storage
SD card support (up to 2 GB)
Integrated Motion Control
Yes
Servo Drive Compatibility
Kinetix servo systems
Power Dissipation
Approx. 5–6 W
Operating Temperature
0°C to 60°C
Storage Temperature
-40°C to 85°C
Mounting Type
DIN rail / panel mount
Dimensions
Approx. 145 × 118 × 87 mm
Weight
Approx. 0.9–1.1 kg
Recommended Related Models
Related Model
Function
1769-L33ERM
Mid-level CompactLogix motion controller
1769-L33ER
Standard Ethernet CompactLogix PLC
1769-L30ER
Mid-range EtherNet/IP controller
Kinetix 5500
Integrated servo drive system
1769-IF8
Analog input module
1769-OB16
Digital output module
Popular Allen Bradley Automation Products
Model
Category
1756-L85E
ControlLogix high-performance PLC
5069-L320ERM
Compact 5000 motion controller
Kinetix 5700
Advanced servo drive system
PanelView Plus
Industrial HMI
Stratix 5700
Industrial Ethernet switch
POINT I/O 1734 Series
Distributed I/O modules
Industrial Applications
The 1769-L36ERM is designed for advanced industrial automation systems requiring synchronized multi-axis motion and high-speed machine coordination.
Typical applications include:
Robotic automation systems
High-speed packaging machinery
CNC and precision positioning systems
Automated assembly equipment
Material handling and conveyor synchronization
Printing and converting machines
Pharmaceutical production systems
Complex OEM machine platforms
Its integrated motion capability makes it ideal for demanding applications where precise timing and coordinated control are critical.
Key Advantages
Advanced Integrated Motion Control
Supports up to 16 CIP Motion axes for precise synchronized control of servo-driven systems.
High Processing Capacity
With 3 MB memory, the controller efficiently handles complex machine logic, motion calculations, and large data structures.
Dual EtherNet/IP Communication
Embedded Ethernet switching with DLR support improves network flexibility and operational reliability.
Large Compact I/O Expansion
Supports up to 30 Compact I/O modules for highly scalable automation architectures.
Optimized for Modern Smart Manufacturing
Ideal for Industry 4.0 environments requiring intelligent networking, motion coordination, and high-speed automation performance.
Technical FAQs
1. What is the 1769-L36ERM used for?
It is used for industrial automation systems requiring integrated multi-axis motion control and EtherNet/IP communication.
2. How many motion axes does it support?
It supports up to 16 CIP Motion axes over EtherNet/IP.
3. Does it support servo drives?
Yes. It is commonly integrated with Allen Bradley Kinetix servo drive systems.
4. What communication network does it use?
It uses EtherNet/IP with CIP Motion capability.
5. Does it support Device Level Ring (DLR)?
Yes. DLR provides Ethernet network redundancy and improved reliability.
6. How much user memory does it provide?
It includes 3 MB of user memory for advanced automation applications.
7. What software is used for programming?
It is programmed using Studio 5000 Logix Designer.
8. How many Compact I/O modules can it support?
It supports up to 30 Compact I/O modules depending on system configuration.
9. Is it suitable for high-speed machinery?
Yes. It is specifically designed for high-performance synchronized machine automation.
10. Why is the 1769-L36ERM widely used in advanced automation systems?
Because it combines powerful PLC processing, integrated multi-axis motion control, dual EtherNet/IP networking, and scalable Compact I/O architecture in a high-performance industrial controller platform.
