Introduction

The Allen Bradley 1762-IA8 MicroLogix AC Input Module provides reliable, compact, and precise digital AC input capability for MicroLogix controllers. Its small footprint and lightweight design make it ideal for expanding input channels in industrial automation, ensuring accurate signal acquisition and robust performance in harsh environments.

Technical Specifications

Feature	Specification
Module Type	AC Input Module
Dimensions (L × W × H)	90 × 40 × 87 mm
Weight	0.209 kg (0.461 lb)
Function	AC digital input acquisition
Compatibility	MicroLogix 1000 and 1200 controllers
Protection	Industrial-grade durability
Operating Environment	Small to medium industrial automation systems

Applications

The Allen Bradley 1762-IA8 MicroLogix AC Input Module is a compact and reliable input solution for industrial automation. Its applications include:

Receiving AC digital signals from switches, sensors, and control devices
Expanding MicroLogix 1000 and 1200 controllers for additional input channels
Monitoring status signals in manufacturing and process automation systems
Supporting small-scale automated machinery and logic control
Integration into distributed control systems for real-time input processing

This module ensures precise and reliable digital input acquisition for a wide range of industrial applications.

Advantages

High Signal Accuracy: Ensures consistent and accurate AC input reading
Compact Design: 90 × 40 × 87 mm for easy installation in space-constrained panels
Lightweight: Weighs only 0.209 kg (0.461 lb), simplifying mounting
Easy Integration: Fully compatible with MicroLogix 1000 and 1200 series controllers
Industrial Reliability: Designed for consistent operation in harsh industrial environments

Technical FAQs

Q: What is the function of the 1762-IA8 module?
A: It receives AC digital signals from industrial sensors and switches.
Q: How many input channels does it provide?
A: It provides 8 AC digital input channels.
Q: What is the exact weight of the module?
A: 0.209 kg (0.461 lb).
Q: Can it operate continuously in industrial conditions?
A: Yes, it is designed for 24/7 industrial use.
Q: Is it compatible with MicroLogix 1000 controllers?
A: Yes, it is fully compatible with MicroLogix 1000 and 1200 controllers.
Q: What AC voltage range does it support?
A: Typically 120 VAC; refer to datasheet for detailed specifications.
Q: How is it mounted?
A: Panel-mounted or installed on MicroLogix controller expansion slots.
Q: Can it detect short circuits or wiring faults?
A: Yes, the module provides diagnostics for input errors.
Q: Does it support high-speed input scanning?
A: Yes, it supports fast input scanning compatible with MicroLogix controllers.
Q: What is the expected lifespan of this input module?
A: Over 10 years under standard industrial operating conditions.
