Introduction

The Allen Bradley 1763-L16AWA MicroLogix 1100 Controller combines compact design with reliable performance for small-scale industrial automation. Lightweight, panel-mountable, and capable of handling real-time control, this controller is perfect for manufacturing lines and process automation where space and reliability are critical.

Technical Specifications

Feature	Specification
Module Type	Programmable Controller
Dimensions (L × W × H)	110 × 87 × 90 mm
Weight	0.9 kg (1.984 lb)
Digital I/O Points	16 points
Expandable Modules	Supports additional MicroLogix 1100 modules
Programming Software	RSLogix 500
Communication	DF1, Modbus
Operating Environment	Industrial automation
Protection	Industrial-grade durability

Applications

The Allen Bradley 1763-L16AWA MicroLogix 1100 Programmable Controller is ideal for compact industrial automation projects. Common applications include:

Controlling small machinery, conveyors, and pumps
Automating repetitive processes in manufacturing lines
Collecting sensor input data and driving actuators with precision
Implementing simple sequence control logic
Integrating with MicroLogix 1100 I/O and communication modules

Its compact design makes it perfect for panel-mounted automation solutions with limited space.

Advantages

Compact and Lightweight: 110 × 87 × 90 mm, 0.9 kg (1.984 lb), easy to install in tight spaces
Reliable Performance: Optimized for small-scale industrial automation
Expandable: Supports additional MicroLogix 1100 I/O modules for flexible configuration
Fast Scan Times: Ensures real-time monitoring and control
Industrial-Grade Durability: Resistant to electrical noise and standard industrial environmental conditions

Technical FAQs

Q: How many I/O points does this controller support?
A: 16 digital I/O points, expandable with additional modules.
Q: Which programming software is compatible?
A: RSLogix 500 software is fully compatible with MicroLogix 1100 controllers.
Q: Can it communicate with other devices?
A: Yes, supports DF1 and Modbus protocols for data exchange.
Q: Is it suitable for continuous industrial operation?
A: Yes, designed for 24/7 operation under standard industrial conditions.
Q: Can it integrate analog I/O modules?
A: Yes, compatible with MicroLogix 1100 analog input/output modules.
Q: What is the typical scan time?
A: Optimized for fast scanning to provide real-time control, typically under 2 ms per I/O point.
Q: How is the controller mounted?
A: Panel-mounted using standard DIN rails or mounting brackets.
Q: Does it provide diagnostic capabilities?
A: Yes, it monitors I/O faults and system errors for reliable operation.
Q: Can it handle timed operations?
A: Yes, it supports timers, counters, and real-time clock operations.
Q: What is the expected operational lifespan?
A: Over 10 years under normal industrial conditions.
