Allen Bradley 1771-A4B I/O Chassis

Industrial Applications

The 1771-A4B is used in large PLC-5 based control systems where high I/O capacity is required in a single rack configuration.

Common applications include:

• Automotive manufacturing systems
• Large process control plants
• Power generation facilities
• Oil and gas processing systems
• Water and wastewater treatment plants
• Heavy industrial machinery
• Continuous production lines
• Factory-wide automation systems

Its high slot capacity makes it suitable for complex control architectures with extensive field device integration.

Key Functional Characteristics

The 1771-A4B is engineered for high-density modular automation systems requiring stable long-term operation.

Key characteristics include:

• 16-slot high-capacity chassis design
• Supports large-scale PLC-5 I/O configurations
• Backplane communication between all modules
• Compatible with multiple PLC-5 power supplies
• Industrial-grade rack/panel mounting design
• Suitable for centralized control architectures
• Designed for long lifecycle industrial systems

It is one of the highest-capacity chassis options in the PLC-5 1771 family.

Technical FAQs

1. What is the 1771-A4B used for?

It is a PLC-5 chassis used to mount and connect up to 16 system modules.

2. How many slots does it provide?

It has 16 module slots.

3. What PLC system is it part of?

It belongs to the Allen-Bradley PLC-5 / 1771 I/O series.

4. Can it be used with modern PLC systems?

No. It is a legacy chassis and not compatible with CompactLogix or ControlLogix.

5. What modules can be installed?

CPU, I/O modules, communication modules, and power supply modules.

6. What is the backplane voltage?

Approximately 5.25 V DC.

7. What is its main advantage over smaller chassis?

Higher slot density allows more I/O modules in a single rack.

8. What is the mounting type?

It supports rack or panel-mounted industrial installation.

9. Is it still used in industry today?

Yes, mainly in legacy PLC-5 systems still in operation.

10. Why are PLC-5 chassis still used?

Because many industrial systems rely on long-life infrastructure and phased modernization strategies instead of full replacement.
