Introduction

The Allen-Bradley 1768-ENBT CompactLogix EtherNet/IP Communication Module delivers high-speed, reliable connectivity for modern industrial automation systems. Its compact size, robust construction, and seamless integration with CompactLogix controllers make it ideal for real-time control, data acquisition, and supervisory network communications.

Technical Specifications

Feature	Specification
Model Number	1768-ENBT
Module Type	CompactLogix EtherNet/IP Communication Module
Dimensions (L x W x H)	132 × 56.7 × 105.1 mm
Weight	0.213 kg (0.47 lb)
Operating Temperature	0°C to 60°C
Network Protocol	EtherNet/IP
Mounting	CompactLogix rack or panel
Indicators	Status, network activity LEDs

Applications

The Allen-Bradley 1768-ENBT is a high-performance communication module designed for seamless network connectivity in industrial automation systems. Its typical applications include:

Enabling Ethernet/IP connectivity for CompactLogix controllers
Linking controllers to supervisory systems, HMIs, and SCADA networks
Data transfer and remote monitoring for industrial equipment
Integration in manufacturing, process control, and machine automation systems

This module ensures reliable, real-time communication, making it essential for modern industrial automation environments.

Advantages

High-Speed Ethernet/IP Communication: Supports rapid, deterministic data exchange.
Compact Design: Minimal footprint for easy integration into CompactLogix racks.
Seamless Integration: Fully compatible with Allen-Bradley CompactLogix controllers.
Robust and Industrial-Grade: Resilient to vibration, temperature variations, and electrical noise.
Plug-and-Play Connectivity: Simplifies installation and network configuration.

Technical FAQs

Which controllers is this module compatible with?
It is designed for Allen-Bradley CompactLogix 1768 series controllers.
What network protocols are supported?
Supports EtherNet/IP for industrial automation networking.
Is configuration software required?
Yes, Studio 5000 Logix Designer is recommended for network setup and configuration.
Can it handle multiple Ethernet nodes?
Yes, it supports multiple nodes and connections for scalable networks.
What is the operating temperature range?
0°C to 60°C (32°F to 140°F).
Does it support real-time I/O updates?
Yes, the module supports deterministic real-time data exchange.
Is it compatible with existing Rockwell Automation devices?
Yes, fully compatible with other Allen-Bradley Ethernet/IP-enabled devices.
Can it be mounted on a standard CompactLogix rack?
Yes, it integrates seamlessly into 1768 CompactLogix racks.
Does it include LED indicators for status?
Yes, LEDs display communication, network activity, and module status.
Is it suitable for critical industrial applications?
Yes, it is designed for high-reliability industrial automation systems.
