The Allen Bradley 20-750-2262C-2R is a remote Human Interface Module (HIM) communication cable designed for PowerFlex 750-Series AC drives and compatible Allen Bradley drive systems. This cable enables secure and stable remote mounting of HIM devices, allowing operators to conveniently access drive configuration, diagnostics, and monitoring functions from control panel doors or remote operator stations.
Built for industrial environments, the 20-750-2262C-2R provides dependable communication between the drive and HIM while simplifying panel layout and improving operator accessibility in motor control applications.
Technical Specifications
| Specification | Details |
|---|---|
| Manufacturer | Allen Bradley (Rockwell Automation) |
| Model Number | 20-750-2262C-2R |
| Product Family | PowerFlex 750-Series Accessories |
| Product Type | HIM Communication Cable |
| Cable Function | Remote HIM connection |
| Compatible Devices | PowerFlex 750-Series HIMs and drives |
| Cable Length | 2 meters |
| Connector Type | RJ45 industrial communication connectors |
| Communication Interface | DPI / HIM communication interface |
| Supported HIM Models | 20-HIM-A6, 20-HIM-C6S and compatible models |
| Installation Type | Panel-mounted remote HIM connection |
| Cable Construction | Industrial-grade shielded cable |
| Signal Type | Serial communication |
| Environmental Rating | Industrial control environments |
| Operating Temperature | 0°C to 50°C |
| Storage Temperature | -40°C to 70°C |
| Mounting Compatibility | Remote-mounted operator interface systems |
| Application Compatibility | AC drive control and monitoring systems |
Physical Dimensions & Weight (L × W × H Combined)
| Parameter | Specification |
|---|---|
| Dimensions (L × W × H) | 2000 × 12 × 12 mm |
| Weight | Approx. 0.18 kg |
Recommended Related Models
The 20-750-2262C-2R is commonly used with PowerFlex drives and HIM operator interface products.
| Related Model | Description |
|---|---|
| 20-HIM-A6 | LCD Human Interface Module |
| 20-HIM-C6S | Full-color HIM interface |
| 20-750-20COMM | Dual communication carrier module |
| 20-750-ENETR | EtherNet/IP communication adapter |
| 20-750-DNET | DeviceNet communication adapter |
| 20F11NC140JA0NNNNN | PowerFlex 753 AC drive |
| 20G11NC072AA0NNNNN | PowerFlex 755 AC drive |
| 20-750-S | Safe torque-off module |
| 20-750-UFB-1 | Universal feedback module |
| 25B-D013N114 | PowerFlex 525 drive |
