The Allen Bradley 20-750-APS is an auxiliary power supply module designed for PowerFlex 750-Series AC drives. It provides external control power to the drive’s control circuitry, communication modules, and HIM interfaces without energizing the main power section of the drive. This functionality allows technicians and operators to configure, diagnose, and maintain the drive safely while the main input power remains disconnected.
Engineered for industrial automation environments, the 20-750-APS enhances maintenance efficiency, simplifies commissioning, and improves system accessibility in applications where uninterrupted control-level access is essential.
Technical Specifications
| Specification | Details |
|---|---|
| Manufacturer | Allen Bradley (Rockwell Automation) |
| Model Number | 20-750-APS |
| Product Family | PowerFlex 750-Series |
| Module Type | Auxiliary Power Supply Module |
| Primary Function | Supplies external control power to drive electronics |
| Compatible Drives | PowerFlex 753 / 755 Series |
| Input Voltage | 24V DC nominal |
| Operating Voltage Range | 18–30V DC |
| Output Function | Powers control circuitry and communication modules |
| HIM Support | Yes |
| Communication Support | Supports active communication modules during maintenance |
| Installation Type | Internal drive-mounted accessory |
| Connection Type | Plug-in module |
| Power Consumption | Low-power auxiliary operation |
| Diagnostics | Status indication via drive system |
| Operating Temperature | 0°C to 50°C |
| Storage Temperature | -40°C to 70°C |
| Relative Humidity | 5–95% non-condensing |
| Environmental Rating | Industrial open-style installation |
| Certifications | UL, CE, cUL listed |
Physical Dimensions & Weight (L × W × H Combined)
| Parameter | Specification |
|---|---|
| Dimensions (L × W × H) | Approx. 120 × 85 × 35 mm |
| Weight | Approx. 0.20 kg |
Recommended Related Models
The 20-750-APS is commonly used with PowerFlex communication modules, HIM interfaces, and industrial drive accessories.
| Related Model | Description |
|---|---|
| 20-750-20COMM | Dual communication carrier module |
| 20-750-ENETR | EtherNet/IP communication adapter |
| 20-750-DNET | DeviceNet communication adapter |
| 20-HIM-A6 | LCD Human Interface Module |
| 20-HIM-C6S | Full-color HIM interface |
| 20-750-2262C-2R | HIM remote cable |
| 20-750-UFB-1 | Universal feedback module |
| 20-750-S | Safe torque-off module |
| 20F11NC140JA0NNNNN | PowerFlex 753 AC drive |
| 20G11NC072AA0NNNNN | PowerFlex 755 AC drive |
