Introduction

The Allen Bradley 1791D-0B16P CompactBlock I/O Output Basic Module is a reliable, compact solution for digital output management in industrial automation. With 16 output channels and industrial-grade construction, it provides precise, high-speed output performance. Perfect for integration into CompactBlock LDX I/O systems, it ensures efficient, dependable operation in space-constrained industrial environments.

Technical Specifications

Parameter	Specification
Dimensions (L x W x H)	150 × 38 × 48 mm
Weight	0.2 kg (0.44 lb)
Function	Digital Output Module
Channels	16 Digital Output Channels
Operating Voltage	24 VDC (typical)
Operating Temperature	0°C to 60°C
Mounting	CompactBlock LDX I/O Rack
Connectivity	Digital Output to Actuators and Indicators
Compliance	CE, Industrial-Grade Standards
Application	CompactBlock Automation, Machine Control, Process Control

Applications

The Allen Bradley 1791D-0B16P CompactBlock I/O Output Basic Module is designed for reliable and fast digital output control in compact automation systems. Typical applications include:

Driving solenoids, relays, and indicator devices in industrial automation systems
Integration with CompactBlock LDX I/O networks for scalable automation
Supporting distributed control systems and machine automation
Industrial environments requiring fast, reliable, and compact digital output modules
Process control and manufacturing systems where space-saving and efficiency are critical

This module ensures precise output control for efficient automation and process management.

Advantages

Compact and Lightweight: 150 × 38 × 48 mm and 0.2 kg (0.44 lb), ideal for tight panel spaces.
High Reliability: Provides stable digital output performance under demanding industrial conditions.
Fast Switching Capability: Supports rapid output transitions for real-time control.
Industrial-Grade Construction: Resistant to vibration, electrical noise, and temperature fluctuations.
Seamless Integration: Designed for use with CompactBlock LDX I/O systems.
Plug-and-Play Installation: Quick and easy setup for system expansion or replacement.

Technical FAQs

Q: What is the primary function of the 1791D-0B16P?
A: Provides 16 digital output channels for industrial automation systems.
Q: Is it compatible with other CompactBlock modules?
A: Yes, designed to integrate seamlessly with CompactBlock LDX I/O networks.
Q: What types of devices can it drive?
A: Supports solenoids, relays, actuators, and indicator devices.
Q: What is the operating voltage?
A: Typically 24 VDC for digital output signals.
Q: Can it operate in harsh industrial environments?
A: Yes, built to withstand vibration, temperature variations, and electrical interference.
Q: How is it mounted?
A: Installs easily into CompactBlock LDX I/O racks.
Q: Does it support high-speed output switching?
A: Yes, designed for fast response in real-time control applications.
Q: Is configuration software required?
A: Yes, setup and channel configuration are performed via standard CompactBlock programming tools.
Q: What is the operating temperature range?
A: 0°C to 60°C, suitable for most industrial environments.
Q: What maintenance is required?
A: Minimal; periodic inspection ensures proper connections and output integrity.
