The Allen Bradley 2090-K6CK is a Kinetix 6000 series low-profile connector kit designed for servo drive systems used in high-performance motion control applications. It belongs to the 2090 motion accessories family, providing reliable electrical connection between Kinetix servo drives, motors, and feedback devices.
This connector kit is widely used in multi-axis motion systems, robotics, packaging machinery, and precision automation equipment, where stable signal integrity and compact wiring design are essential.
It is specifically engineered for Kinetix 6000 / 6200 / 6500 / 7000 drive platforms, ensuring compatibility across Rockwell’s integrated motion ecosystem.
Technical Specifications
| Specification | Details |
|---|---|
| Manufacturer | Allen Bradley (Rockwell Automation) |
| Model Number | 2090-K6CK |
| Product Family | Kinetix Motion Accessories |
| Product Type | Servo Drive Connector Kit |
| Compatible Drives | Kinetix 6000 / 6200 / 6500 / 7000 |
| Connector Type | Low-profile D-sub / terminal block style (varies by variant) |
| Function | Motor feedback / I/O / auxiliary signal connection |
| Pin Configurations | 15-pin / 26-pin / 44-pin variants available |
| Application | Servo motor feedback and drive interfacing |
| Wiring Design | Modular, reduced wiring complexity |
| Mounting Style | Drive-mounted connector interface |
| Shielding | EMI-protected design for industrial environments |
| Operating Environment | Industrial motion control systems |
| Compliance | UL, CE, KC (varies by kit variant) |
Physical Dimensions & Weight (L × W × H Combined)
| Parameter | Specification |
|---|---|
| Dimensions (L × W × H) | Approx. 300 × 250 × 160 mm (varies by connector variant) |
| Weight | Approx. 0.25 – 0.95 kg depending on configuration |
Recommended Related Models
The 2090-K6CK is part of a broader Kinetix motion control accessory ecosystem.
| Related Model | Description |
|---|---|
| 2090-K6CK-D15M | 15-pin motor feedback connector kit |
| 2090-K6CK-D15MF | Filtered motor feedback connector kit |
| 2090-K6CK-D26M | 26-pin I/O connector kit |
| 2090-K6CK-D44M | 44-pin safety and I/O connector kit |
| 2090-K6CK-KENDAT | EnDat feedback compatibility connector |
| Kinetix 6000 Drive Series | Servo drive platform |
| Kinetix 6500 Drive Series | Ethernet-based motion system |
| 2090 motor cables | Servo motor connection cables |
| 2090 feedback cables | Encoder and feedback wiring |
| 2090 accessory kits | Motion system wiring accessories |
