The Allen Bradley 2094-BC07-M05 is a Kinetix 6000 series Integrated Axis Module (IAM) designed for high-power multi-axis servo applications. It combines converter and inverter functionality into a single modular unit, enabling coordinated motion control in demanding automation environments such as CNC machining, robotics, and high-speed production lines.
This model is engineered for large-scale industrial motion systems where high continuous power, strong dynamic response, and stable DC bus architecture are required. It is typically used within Rockwell Automation’s Logix-integrated motion platform, supporting synchronized multi-axis control.
Technical Specifications
| Specification | Details |
|---|---|
| Manufacturer | Allen Bradley (Rockwell Automation) |
| Model Number | 2094-BC07-M05 |
| Product Family | Kinetix 6000 / 6200 / 6500 |
| Module Type | Integrated Axis Module (IAM) |
| Input Voltage | 324–528V AC, 3-phase (360–480V nominal) |
| Input Frequency | 47–63 Hz |
| Continuous Output Power | 45 kW |
| Inverter Output Current | ~49 A |
| DC Bus Voltage Range | ~458–747 VDC |
| Efficiency | ~95–97% |
| Internal Shunt Power | 200 W continuous / high peak capability |
| Safety Function | STO (Safe Torque Off not available on some variants) |
| System Architecture | Shared DC bus multi-axis drive system |
| Cooling Method | Forced air (cabinet ventilation required) |
| Operating Temperature | 0°C to 50°C |
| Mounting Type | Kinetix 6000 drive chassis |
Physical Dimensions & Weight (L × W × H Combined)
| Parameter | Specification |
|---|---|
| Dimensions (L × W × H) | ~196 × 302 × 272 mm (varies slightly by revision) |
| Weight | ~9.8 – 10.7 kg |
Recommended Related Models
The 2094-BC07-M05 is typically used in a full Kinetix 6000 motion system architecture.
| Related Model | Description |
|---|---|
| 2094-BM05-S | Matching axis module variant |
| 2094-SE02F-M00-S0 | System interface module |
| 2090-K6CK-D44S0 | STO / safety connector kit |
| Kinetix 6000 / 6200 / 6500 | Servo drive platform |
| 2198-S086-ERS3 | Recommended newer replacement system |
| 1756-L8x | ControlLogix motion controller |
| 5069-L320ER | CompactLogix controller |
| MPL / VPL Servo Motors | Compatible motor families |
| 2090 motor cables | Power and feedback wiring |
| 1734-AENTR | Distributed I/O adapter |
