The Allen Bradley 2094-BMP5-M is a Kinetix 6200 series Axis Power Module designed for high-performance multi-axis servo drive applications. It operates within Rockwell Automation’s shared DC-bus architecture, delivering precise motion control for synchronized industrial automation systems.
This module is commonly used in CNC machines, robotics, packaging systems, and advanced manufacturing lines, where stable torque output, fast dynamic response, and scalable motion control are essential.
As part of the Kinetix 6200/6500 platform, it must be paired with compatible system modules and control interfaces to form a complete servo drive system.
Technical Specifications
| Specification | Details |
|---|---|
| Manufacturer | Allen Bradley (Rockwell Automation) |
| Model Number | 2094-BMP5-M |
| Product Family | Kinetix 6200 / 6500 |
| Module Type | Axis Power Module |
| Input Voltage | 360–480V AC, 3-phase |
| DC Bus Voltage | ~650V DC |
| Continuous Output Current | ~2.8 A (RMS) |
| Peak Output Current | ~7.0 A (RMS) |
| Output Power | ~1.8 kW |
| Output Voltage | 0–480V AC, 3-phase |
| Output Frequency | Up to 800 Hz |
| Control Interface | SERCOS / Logix integrated motion system |
| Safety Function | STO (varies by system configuration) |
| PWM Switching Frequency | ~8 kHz |
| Efficiency | Up to ~97–98% |
| Cooling Method | Forced air (cabinet ventilation required) |
| Mounting Type | Kinetix 6200 rack/chassis system |
| Operating Temperature | 0°C to 50°C |
Physical Dimensions & Weight (L × W × H Combined)
| Parameter | Specification |
|---|---|
| Dimensions (L × W × H) | 141 × 302 × 426 mm |
| Weight | ~5.9 kg |
Recommended Related Models
The 2094-BMP5-M is typically used in a complete Kinetix 6200 system architecture.
| Related Model | Description |
|---|---|
| 2094-BC02-M02-S | Matching integrated axis module |
| 2094-BM02-S | Axis module variant |
| 2094-SE02F-M00-S0 | System interface module |
| 2090-K6CK-D44S0 | Safety / STO connector kit |
| Kinetix 6200 / 6500 series | Core motion platform |
| 2198-D series | Modern Kinetix replacement platform |
| 1756-L8x | ControlLogix motion controller |
| 5069-L320ER | CompactLogix controller |
| MPL / VPL servo motors | Compatible motor families |
| 2090 motor cables | Servo power and feedback wiring |
