The Allen Bradley 2094-PRS1 is a Kinetix 6000 Slim Power Rail designed to support a single Integrated Axis Module (IAM) in Rockwell Automation’s Kinetix 6000 motion control system. It serves as the mechanical and electrical mounting base that distributes power and communication within a compact single-axis servo configuration.
This model is widely used in small-scale CNC machines, standalone servo axes, packaging equipment, and compact automation systems, where a full multi-slot drive rack is not required.
The slim design makes it ideal for space-constrained control cabinets, while still maintaining full compatibility with Kinetix 6000 / 6200 / 6500 drive families.
Technical Specifications
| Specification | Details |
|---|---|
| Manufacturer | Allen Bradley (Rockwell Automation) |
| Model Number | 2094-PRS1 |
| Product Family | Kinetix 6000 |
| Module Type | Slim Power Rail |
| System Capacity | 1 Integrated Axis Module |
| Supported Voltage | 230V / 460V AC drive systems |
| Drive Compatibility | Kinetix 6000 / 6000M / 6200 / 6500 |
| Function | Mechanical mounting + power distribution rail |
| System Architecture | Single-axis servo configuration |
| Installation Style | Cabinet-mounted rail with bracket |
| Protection | Finger-safe slot cover design |
| Application Type | Standalone servo axis systems |
| Operating Environment | Industrial cabinet (IP20 system level) |
Physical Dimensions & Weight (L × W × H Combined)
| Parameter | Specification |
|---|---|
| Dimensions (L × W × H) | ~134.6 × 88.9 × 25 mm (approx. 5.3 × 3.5 × 1.0 in) |
| Weight | ~1.1 – 1.25 kg |
Recommended Related Models
The 2094-PRS1 is typically used in compact Kinetix 6000 single-axis systems.
| Related Model | Description |
|---|---|
| 2094-BM02 | Axis module compatible with slim rail setups |
| 2094-BC02-M02-S | Integrated axis module variant |
| 2094-SE02F-M00-S0 | System interface module |
| 2090-K6CK-D15M | Servo feedback connector kit |
| 2090-K6CK-D44S0 | Safety STO connector kit |
| MPL / VPL servo motors | Compatible motor families |
| 1756-L8x | ControlLogix motion controller |
| 5069-L320ER | CompactLogix controller |
| 1606-XLE series | Power supply units |
| 1734-AENTR | Distributed I/O adapter |
