The Allen-Bradley 20AC1P3A0AYNANC0 is a compact yet highly capable PowerFlex 70 AC drive module engineered for accurate low-power motor control in industrial automation environments. Designed by Rockwell Automation, this drive combines advanced vector control technology with flexible integration capability, making it ideal for applications requiring dependable speed regulation, smooth acceleration, and optimized energy efficiency.
Despite its compact frame size, the drive delivers impressive operational stability and supports a wide range of industrial motor applications. Its integrated EMC filtering, enhanced control functionality, and durable PowerFlex architecture help reduce installation complexity while improving overall system performance.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Series | PowerFlex 70 |
| Drive Type | AC Variable Frequency Drive |
| Input Voltage | 380–480V AC, 3-Phase |
| Continuous Output Current | 1.3 A |
| Normal Duty Power Rating | 0.37 kW |
| Heavy Duty Power Rating | 0.25 kW |
| Control Method | Enhanced Vector Control with 24V I/O |
| Enclosure Type | IP20 / NEMA Type 1 |
| Frame Size | Frame A |
| Brake IGBT | Installed |
| Internal Brake Resistor | Not Included |
| Communication Module | None Installed |
| EMC Filter | Integrated |
| Output Frequency Range | 0–500 Hz |
| Efficiency | Approx. 97.5% |
| Operating Temperature | 0 to 50°C |
| Humidity Range | 5–95% Non-Condensing |
Dimensions & Weight
| Item | Value |
|---|---|
| Dimensions (H × W × D) | 225.7 × 122.4 × 179.8 mm (8.89 × 4.82 × 7.08 in) |
| Weight | 2.71 kg (approx. 5.97 lbs) |
Its compact design allows efficient panel integration in space-constrained control cabinets while maintaining reliable thermal performance.
Recommended Related Models
The following Allen-Bradley models are commonly used alongside or as alternatives to the 20AC1P3A0AYNANC0:
- 20AC011A0AYNANC0 – Higher-capacity PowerFlex 70 drive
- 20AC037A0AYNANC0 – Mid-range industrial motor control solution
- 20AD2P1A0AYNNNC0 – PowerFlex 70 drive for expanded motor applications
- PowerFlex 525 Series – Compact modern replacement platform
- 20-HIM-A6 HIM Module – Local parameter configuration and diagnostics
These options provide scalable motor control solutions for both legacy systems and modern automation upgrades.
