The Allen-Bradley 2198-BARCON-85DC200 is a DC bus bar connector module engineered for the Kinetix 5700 servo drive platform. Designed to provide secure and efficient DC bus interconnection between multiple servo drives, this component helps simplify cabinet wiring while improving power distribution reliability in advanced motion control systems.
As part of Rockwell Automation’s integrated motion architecture, the 2198-BARCON-85DC200 enables clean multi-axis drive installation with reduced wiring complexity, improved thermal performance, and optimized panel layout efficiency. It is commonly used in high-performance automation systems where synchronized motion, scalability, and long-term electrical stability are essential.
Its heavy-duty design supports industrial applications requiring stable DC bus continuity across multiple Kinetix servo drive modules.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Type | DC Bus Bar Connector Module |
| Product Series | Kinetix 5700 |
| Compatible Drives | 2198 Kinetix 5700 Servo Drives |
| Rated Bus Voltage | 85–264V DC |
| Current Capacity | 200 A |
| Mounting Type | Direct bus bar connection |
| Material | Industrial-grade conductive alloy |
| Application | Multi-axis servo power distribution |
| Cooling Requirement | Passive |
| Operating Temperature | 0°C to 50°C |
| Storage Temperature | -40°C to 70°C |
| Humidity Range | 5–95% non-condensing |
| Compliance | Industrial motion control standards |
Dimensions & Weight
| Item | Value |
|---|---|
| Dimensions (H × W × D) | ~35 × 180 × 25 mm |
| Weight | ~0.32 kg |
Its compact low-profile structure allows efficient integration into high-density motion control cabinets while maintaining secure electrical bus continuity.
