The Allen-Bradley 2198-H008-ERS is a Kinetix 5500 servo drive module designed for advanced industrial motion control systems requiring precision positioning, fast network communication, and compact cabinet integration. As part of Rockwell Automation’s Integrated Architecture platform, this servo drive delivers synchronized motion performance with seamless EtherNet/IP connectivity and embedded safety functionality.
Engineered for medium-power servo applications, the 2198-H008-ERS supports high-speed automation equipment such as packaging machinery, robotic systems, indexing tables, and automated assembly lines. Its integrated motion capabilities simplify system configuration while helping OEMs reduce wiring complexity and improve machine scalability.
The drive combines efficient thermal performance with a narrow industrial design, making it suitable for high-density control panels and modern manufacturing environments.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Series | Kinetix 5500 |
| Product Type | Servo Drive Module |
| Input Voltage | 190–528V AC |
| Input Phase | Single-Phase / Three-Phase |
| Input Frequency | 47–63 Hz |
| Continuous Output Current | 4.0 A |
| Peak Output Current | 8.0 A |
| Continuous Output Power | Up to 1.8 kW |
| Communication | Dual-Port EtherNet/IP |
| Safety Function | Integrated Safe Torque-Off (STO) |
| Dynamic Brake Chopper | Integrated |
| Dynamic Brake Resistor | Built-in |
| Feedback Support | Multi-turn and single-turn encoder support |
| Control Modes | Position / Speed / Torque Control |
| Cooling Method | Air Cooled |
| Mounting Type | Panel Mount |
| Enclosure Type | IP20 / Open Type |
| Operating Temperature | 0°C to 50°C |
| Humidity Range | 5–95% non-condensing |
Dimensions & Weight
| Item | Value |
|---|---|
| Dimensions (H × W × D) | 230 × 55 × 196 mm |
| Weight | ~1.6 kg |
Its compact industrial design helps optimize cabinet layout while maintaining efficient airflow and reliable continuous-duty performance.
Recommended Related Models
- 2198-H003-ERS2 – Lower-power compact Kinetix 5500 drive
- 2198-H015-ERS – Higher-current servo drive option
- 2198-D006-ERS3 – Kinetix 5700 dual-axis servo drive
- 2198-DB20-F – Dynamic brake module
- 2198-BARCON-85DC200 – DC bus connector module
These products support scalable and synchronized servo architectures for industrial automation systems.
