Introduction

The Allen Bradley 2198-H025-ERS2 Kinetix 5500 Servo Driver is engineered for modern industrial automation systems that demand high-speed communication, precise motion control, and simplified system architecture.

Technical Specifications

Parameter	Specification
Series	Kinetix 5500
Model	2198-H025-ERS2
Rated Output Current	25 A
Control Network	EtherNet/IP
Safety Function	Safe Torque Off (STO)
Cooling Method	Forced air cooling
Mounting Type	Panel mounted
Operating Temperature	0°C to 50°C
Storage Temperature	-40°C to 70°C
Humidity	5%–95% non-condensing
Dimensions	265 x 58 x 200 mm
Weight	2.3 kg

Recommended Related Models

Model	Product Name
2198-H015-ERS2	Kinetix 5500 Servo Drive 15A
2198-H040-ERS2	Kinetix 5500 Servo Drive 40A
2198-H025-ERS	Kinetix 5500 Servo Drive Standard Variant
2198-H008-ERS2	Kinetix 5500 Servo Drive 8A Compact

Popular Related Models

Model	Product Name
2198-H070-ERS2	Kinetix 5500 Servo Drive 70A High Power
2198-H020-ERS2	Kinetix 5500 Servo Drive 20A Mid Range
2198-H100-ERS2	Kinetix 5500 Servo Drive 100A Heavy Duty
2198-H010-ERS2	Kinetix 5500 Servo Drive 10A Compact Version

Applications

• High-speed packaging machinery requiring synchronized multi-axis motion control
Ensures precise timing and coordination in fast-cycle production environments where throughput and consistency are critical.

• Robotics systems with precision pick-and-place positioning requirements
Delivers stable and repeatable motion control for robotic handling, assembly, and sorting tasks.

• Semiconductor and electronics manufacturing equipment with micro-level accuracy needs
Supports highly precise positioning required in delicate manufacturing and component placement processes.

• Automated assembly lines demanding tight motion coordination via EtherNet/IP
Enables synchronized multi-axis control across distributed automation systems with real-time communication.

Key Advantages

• Native EtherNet/IP integration enables fast, deterministic motion control communication
Improves real-time coordination and reduces latency in complex automation systems.

• Compact drive architecture reduces cabinet space and simplifies system design
Helps optimize panel layout and supports more efficient machine integration.

• Integrated Safe Torque Off (STO) improves machine safety without extra hardware
Provides built-in safety functionality, reducing external components and system complexity.

• Optimized servo loop performance delivers smooth acceleration and deceleration profiles
Enhances motion stability, reduces mechanical wear, and improves overall machine efficiency.

Technical FAQs

1. What communication protocol does this drive use?
It uses EtherNet/IP for real-time motion and control integration.

2. Is the drive suitable for multi-axis systems?
Yes, it is designed for tightly synchronized multi-axis motion applications.

3. Does it include built-in safety functions?
Yes, it features integrated Safe Torque Off (STO).

4. What type of motors is it compatible with?
It is designed for Kinetix-compatible servo motors within the Rockwell ecosystem.

5. Can it support high-speed positioning tasks?
Yes, it is optimized for fast dynamic response and precise positioning control.

6. Is external motion controller required?
It integrates directly with Logix controllers over EtherNet/IP.

7. How is motion tuning handled?
It supports both automatic tuning and manual parameter optimization.

8. Can it operate in continuous duty cycles?
Yes, it is built for 24/7 industrial operation environments.

9. Does it support regenerative energy handling?
Yes, it can manage regenerative braking depending on system configuration.

10. What industries commonly use this drive?
It is widely used in packaging, robotics, electronics manufacturing, and automation systems.
