The Allen-Bradley 2198-KITCON-D057 is a high-quality connector kit module developed for Rockwell Automation Kinetix servo drive systems. Designed to simplify installation, improve wiring organization, and ensure reliable electrical connectivity, this connector kit is widely used in modern industrial automation and motion control applications.
Built for compatibility with selected Kinetix 5700 and Kinetix 5500 servo drives, the 2198-KITCON-D057 provides factory-engineered connection components that support streamlined panel assembly and faster machine commissioning. It is especially valuable for OEM equipment manufacturers and industrial integrators seeking cleaner cabinet layouts and dependable long-term system performance.
Its rugged industrial design helps maintain stable power and signal transmission in demanding manufacturing environments.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Series | Kinetix Accessories |
| Product Type | Connector Kit Module |
| Compatibility | Kinetix 5500 / Kinetix 5700 Servo Drives |
| Application | Servo drive wiring and installation |
| Connector Style | Plug-in industrial connectors |
| Supported Connections | Power and feedback interfaces |
| Material Construction | Industrial thermoplastic with metal contacts |
| Installation Method | Direct drive connection |
| Environmental Use | Industrial indoor applications |
| Wiring Configuration | Pre-engineered connector layout |
| Mounting Environment | Control cabinet and automation panels |
| Usage Purpose | Motion system assembly and maintenance |
Dimensions & Weight
| Item | Value |
|---|---|
| Dimensions (L × W × H) | 235 × 150 × 50 mm |
| Weight | ~0.7 kg |
The compact connector arrangement supports organized panel layouts while improving installation accessibility and maintenance efficiency.
Recommended Related Models
- 2198-H070-ERS – High-power Kinetix 5500 servo drive
- 2198-H040-ERS2 – Integrated motion servo drive
- 2198-D020-ERS3 – Kinetix 5700 dual-axis servo drive
- 2198-BARCON-85DC200 – Shared DC bus connector module
- 2198-DB20-F – Dynamic brake accessory module
These products are commonly integrated into scalable industrial motion control architectures.
Popular Allen-Bradley Models
- 2198-KITCON-D057
- 2198-H025-ERS
- 2198-H040-ERS2
- 2198-E4015-ERS
- 20-HIM-C6S
Kinetix connection accessories are widely trusted for improving installation efficiency and maintaining reliable industrial drive connectivity.
