The Allen-Bradley 22A-A2P1N103 is a PowerFlex 4 series AC drive module designed for simple, cost-effective motor speed control in small industrial and OEM applications. It delivers stable variable-frequency performance for basic automation tasks where ease of use, compact size, and dependable operation are more important than advanced motion features.
This model is widely applied in conveyors, light pumps, fans, and general-purpose machinery, offering quick setup and minimal parameter configuration. Its straightforward interface and compact Frame A design make it a practical solution for control panels with limited space.
Although it belongs to an earlier generation of Rockwell drives, it remains popular in maintenance and replacement markets due to its robustness and operational simplicity.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Series | PowerFlex 4 |
| Product Type | AC Drive Module |
| Input Voltage | 200–240V AC |
| Input Phase | Single-phase |
| Output Voltage | 0–230V AC |
| Output Current | 2.1 A |
| Output Power | 0.4 kW (0.5 HP) |
| Control Method | V/Hz Control |
| Communication | RS485 |
| Human Interface | Integrated keypad with LED display |
| Braking | No brake IGBT |
| EMC Filtering | Not filtered |
| Protection Features | Overload, short-circuit protection |
| Mounting Type | Panel mount / Frame A |
| Enclosure Rating | IP20 (open type) |
| Frequency Range | 50–60 Hz |
The drive is optimized for basic variable-speed control with stable torque performance across low and mid-speed ranges.
Dimensions & Weight
| Item | Value |
|---|---|
| Dimensions (H × W × D) | 152 × 135 × 80 mm |
| Weight | ~1.0–1.4 kg |
Its compact Frame A footprint makes it suitable for dense control cabinet layouts where space efficiency is critical.
Recommended Related Models
- 22A-A4P5N114 – 1 HP PowerFlex 4 drive upgrade option
- 22A-A2P3N114 – Higher current variant for heavier loads
- 25A series PowerFlex drives – Next-generation replacement platform
- 22B series PowerFlex 40 – Enhanced control performance models
- 2198-H025-ERS – Servo alternative for precision motion systems
These alternatives provide better scalability for users upgrading from basic VFD systems to advanced automation platforms.
Popular Allen-Bradley Models
- 22A-A2P1N103
- 22A-A4P5N114
- 22B-D series PowerFlex 40 drives
- 25A-A2P5N104
- 2198-H040-ERS2
The PowerFlex family remains a global standard for industrial motor speed control across OEM machinery and factory automation systems.
