The Allen-Bradley 22A-A8P0N114 is a PowerFlex 4 series AC drive module designed for general-purpose industrial motor speed control applications requiring higher power capacity within a compact footprint. It delivers consistent V/Hz control performance for pumps, fans, conveyors, and OEM machinery where simplicity, durability, and cost efficiency are key priorities.
This model is positioned in the upper range of the PowerFlex 4 family and is widely used in standard industrial automation systems that require stable 3-phase motor output from a single-phase supply. Despite being a legacy product, it continues to be adopted in retrofit projects and maintenance environments due to its proven reliability and easy integration.
It is officially discontinued, with recommended replacement under the PowerFlex 25A series, but remains widely supported in industrial spare parts markets.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Series | PowerFlex 4 |
| Product Type | AC Drive Module |
| Input Voltage | 200–240V AC |
| Input Phase | Single-phase |
| Output Voltage | 0–230V AC (3-phase output) |
| Output Current | 8.0 A |
| Output Power | 1.5 kW (2 HP) |
| Control Method | V/Hz scalar control |
| Communication | RS-485 |
| Brake Function | Integrated brake IGBT |
| EMC Filter | Built-in CE compliant filter |
| I/O | Digital + analog configurable inputs |
| User Interface | LED keypad with integrated potentiometer |
| Protection | Overload, overvoltage, short-circuit protection |
| Mounting Type | Panel mount / DIN rail compatible |
| Enclosure Rating | IP20 (open type) |
| Frequency Range | 50–60 Hz |
The drive is optimized for straightforward installation and stable motor operation in standard industrial environments.
Dimensions & Weight
| Item | Value |
|---|---|
| Dimensions (H × W × D) | 152 × 135 × 80 mm |
| Weight | ~2.9 kg |
Its compact Frame A/B hybrid structure allows flexible cabinet installation while maintaining thermal stability during continuous operation.
Recommended Related Models
- 22A-A4P5N114 – Lower power PowerFlex 4 variant
- 22A-A2P3N114 – Smaller capacity entry-level drive
- 25A-A8P0N114 – Official next-generation replacement model
- 22B-D series PowerFlex 40 – Enhanced control and vector capability
- 2198-H040-ERS2 – Servo upgrade option for precision motion systems
These alternatives support upgrades from basic VFD control to higher-performance motion architectures.
Popular Allen-Bradley Models
- 22A-A8P0N114
- 22A-A4P5N114
- 25A-A8P0N114
- 22B series PowerFlex 40 drives
- 2198-H070-ERS
The PowerFlex family remains a global standard for compact and cost-effective motor speed control in industrial automation.
