The Allen-Bradley 22A-D4P0N104 is a PowerFlex 4 series AC drive module designed for stable and cost-effective speed control of small industrial motors. It provides V/Hz scalar control, making it ideal for standard applications such as conveyors, pumps, fans, and OEM machinery where simplicity, reliability, and fast commissioning are essential.
Operating in the 480V class, this model delivers consistent performance in compact control cabinet environments. It is widely used in legacy automation systems and retrofit projects due to its robust design and long-standing field reliability.
This product has been officially discontinued (effective June 30, 2025), with a recommended replacement under the PowerFlex 25A series (25A-D4P0N104) for new installations and upgrades.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Series | PowerFlex 4 |
| Product Type | AC Drive Module |
| Input Voltage | 480V AC |
| Input Phase | 3-phase |
| Output Voltage | 0–480V AC (3-phase output) |
| Output Current | 4.0 A |
| Output Power | 1.5 kW (2 HP) |
| Control Method | V/Hz scalar control |
| Communication | RS-485 |
| User Interface | Integrated keypad with LED display |
| Brake Function | Integrated brake IGBT |
| Protection Features | Overload, overvoltage, short-circuit protection |
| Mounting Type | Panel mount (Frame A) |
| Enclosure Rating | IP20 (open type) |
| Frequency Range | 50–60 Hz |
The drive is optimized for straightforward motor control with minimal parameter setup and stable torque behavior in light-to-medium industrial loads.
Dimensions & Weight
| Item | Value |
|---|---|
| Dimensions (H × W × D) | 185 × 136 × 80 mm |
| Weight | ~3.0 kg |
Its compact Frame A enclosure makes it suitable for dense industrial control panels while maintaining adequate thermal performance for continuous operation.
Recommended Related Models
- 25A-D4P0N104 – Next-generation replacement drive
- 22A-A8P0N114 – Similar PowerFlex 4 class variant
- 22B series PowerFlex 40 drives – Enhanced feature upgrade path
- 22A-D1P4N104 – Lower power 480V variant
- 2198-H070-ERS – Servo alternative for high-performance motion control systems
These models support lifecycle upgrades and system modernization for industrial automation users.
Popular Allen-Bradley Models
- 22A-D4P0N104
- 22A-A8P0N114
- 22B series PowerFlex 40
- 25A-D4P0N104
- 2198-H040-ERS2
The PowerFlex ecosystem remains widely deployed due to its durability, global service support, and ease of integration into industrial control systems.
