The Allen-Bradley 22A-D6P0N104 is a PowerFlex 4 series AC drive module designed for efficient and stable speed control of industrial AC motors in the 3 HP (2.2 kW) class. Built for simplicity and durability, it delivers dependable V/Hz scalar control for a wide range of general-purpose applications such as conveyors, pumps, fans, and OEM machinery.
This model is widely used in industrial automation systems where users need a balance of compact footprint, stable torque performance, and easy commissioning. Its straightforward keypad interface and RS-485 communication capability make it suitable for both standalone operation and integrated control systems.
It operates in the 480V industrial class, making it ideal for medium-duty motor control applications in factories and process environments.
Although officially discontinued as of June 30, 2025, it remains heavily used in maintenance and retrofit environments due to its long-term reliability and strong installed base.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Series | PowerFlex 4 |
| Product Type | AC Drive Module |
| Input Voltage | 480V AC |
| Input Phase | 3-phase |
| Output Voltage | 0–480V AC (3-phase output) |
| Output Current | 6.0 A |
| Output Power | 2.2 kW (3 HP) |
| Control Method | V/Hz scalar control |
| Communication | RS-485 |
| User Interface | Integrated keypad with LED display |
| Brake Function | Integrated brake IGBT |
| EMC Filtering | Not filtered (variant dependent) |
| Protection Features | Overload, overvoltage, short-circuit protection |
| Mounting Type | Panel mount (Frame B) |
| Enclosure Rating | IP20 (open type) |
| Frequency Range | 50–60 Hz |
| Power Factor | ~0.98 |
The drive is engineered for stable torque delivery across the full speed range, making it ideal for standard industrial motor loads and continuous operation systems.
Dimensions & Weight
| Item | Value |
|---|---|
| Dimensions (H × W × D) | 190 × 157 × 136 mm |
| Weight | ~1.94 kg |
Its Frame B structure provides improved thermal handling compared to smaller PowerFlex 4 units while maintaining a compact installation footprint.
