Brand:Allen Bradley PLC Item No.:Allen Bradley 22F-A4P2N103 Product Origin:USA Product Dimensions:174 × 72 × 136 mm Product Weight:1.0 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Allen Bradley 22F-A4P2N103 PowerFlex 4M AC Drive is engineered to deliver efficient motor speed control in compact industrial automation environments. Combining reliable operation with simplified configuration, this drive is widely adopted in OEM machinery, conveyor systems, ventilation equipment, and light-duty process automation applications.
Designed for installations where cabinet space and operational efficiency matter, the PowerFlex 4M series provides dependable variable frequency control while maintaining easy commissioning and stable motor performance. Its streamlined architecture allows manufacturers and system integrators to optimize productivity without unnecessary complexity.
Built with industrial-grade durability and intuitive operation, the 22F-A4P2N103 remains a trusted solution for facilities seeking cost-effective and energy-efficient motor management.
Core Technical Data
Specification Item
Details
Manufacturer
Allen Bradley
Product Family
PowerFlex 4M
Catalog Number
22F-A4P2N103
Module Type
AC Drive Module
Rated Power
0.75 kW / 1 HP
Input Voltage
200–240V AC
Input Phase
Single-Phase
Output Current
4.2 A
Output Frequency
0–400 Hz
Input Frequency
50/60 Hz
Enclosure Type
IP20 / NEMA Type Open
Mounting Method
Panel Mount
Frame Size
A
Communication Interface
RS-485 (DSI)
User Interface
Fixed Keypad with Potentiometer
EMC Filter
No CE Filter
Brake IGBT
Omitted
Cooling Method
Forced Air Cooling
Protection Features
Overload, Overvoltage, Undervoltage Protection
Operating Temperature
-10°C to +50°C
Dimensions
Approx. 174 × 72 × 136 mm
Net Weight
Approx. 0.9–1.0 kg
Recommended Compatible & Related Models
Model Number
Product Description
22F-D4P2N103
PowerFlex 4M 480V AC Drive
22B-D4P0N104
PowerFlex 40 AC Drive
25B-D2P3N104
PowerFlex 525 AC Drive
22-COMM-E
EtherNet/IP Communication Adapter
1769-L24ER-QB1B
CompactLogix Controller
2711P-T7C4D8
PanelView Plus HMI
1606-XLE240E
Industrial Power Supply
1734-AENTR
POINT I/O Ethernet Adapter
Frequently Selected Allen Bradley Products
Popular Allen Bradley Model
Product Category
1756-L81E
ControlLogix Controller
5069-IB16
Digital Input Module
1769-OF4
Analog Output Module
20G11NC072JA0NNNNN
PowerFlex 755 Drive
2711R-T4T
Graphic Terminal
1734-IE8C
Analog Input Module
1794-OB16
FLEX I/O Output Module
25B-E024N104
PowerFlex 525 Drive
Industrial Usage Scenarios
The Allen Bradley 22F-A4P2N103 AC Drive is commonly deployed in applications where compact drive performance, energy savings, and dependable motor control are essential.
Typical applications include:
Packaging machinery
Conveyor belt systems
Small pump control
Industrial fan systems
Automated assembly equipment
HVAC systems
Material handling units
Textile production equipment
Food processing machines
OEM compact machinery
Its simplified integration and stable frequency control make it especially suitable for facilities requiring consistent motor operation with reduced engineering complexity.
Operational Benefits
Space-Saving Installation
The compact Frame A structure allows efficient cabinet utilization, making it ideal for high-density industrial panels and machine-level automation systems.
Reliable Speed Regulation
The PowerFlex 4M architecture delivers smooth acceleration and dependable motor response, helping reduce mechanical stress during operation.
Simplified Startup Process
Integrated keypad controls and user-friendly programming significantly reduce commissioning time for maintenance engineers and system integrators.
Energy-Conscious Operation
By optimizing motor speed according to process demand, the drive helps lower energy consumption and improve overall equipment efficiency.
Industrial Communication Capability
Built-in RS-485 communication enables streamlined connectivity with PLCs, HMIs, and supervisory control systems.
Proven Industrial Durability
Allen Bradley’s industrial automation reputation ensures stable long-term performance even in demanding production environments.
