Allen Bradley 2711-B6C16 PanelView 600 HMI Terminal
Allen Bradley 2711-B6C16 PanelView 600 HMI Terminal
0.0
Points
Brand:Allen Bradley PLC Item No.:Allen Bradley 2711-B6C16 Product Origin:USA Product Dimensions:282 × 423 × 112 mm Product Weight:3.5 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Allen Bradley 2711-B6C16 PanelView 600 is a compact Human Machine Interface (HMI) designed for operator interaction, real-time monitoring, and machine control in industrial automation systems. As part of the PanelView Standard 600 series, it is widely used in legacy Allen-Bradley architectures where stable communication, simple operation, and long-term durability are essential.
This model combines a color display with dual-input operation (touchscreen and keypad), allowing operators to interact efficiently with machines even in demanding industrial environments. It is commonly found in packaging lines, material handling systems, and process control panels that rely on DeviceNet or serial communication infrastructure.
Although discontinued, the 2711-B6C16 remains highly relevant in installed base systems due to its reliability, straightforward programming, and strong compatibility with established PLC platforms.
Technical Specifications
Specification
Details
Manufacturer
Allen Bradley (Rockwell Automation)
Product Series
PanelView 600 Standard
Catalog Number
2711-B6C16
Device Type
HMI / Operator Terminal
Display Size
5–5.7 inch Color LCD
Resolution
320 × 234 pixels (QVGA)
Input Type
Touchscreen + Keypad
Function Keys
10 programmable function keys (F1–F10)
Communication Ports
RS-232 (DF1 / DH-485 depending on revision), RS-232 printer/download
Input Power
85–264V AC
Application Memory
~240 KB runtime
Nonvolatile Memory
Flash-based storage
Backlight
Replaceable module (commonly 2711-NL5)
Programming Software
PanelBuilder32
Enclosure Type
Panel mount industrial HMI
Operating Temperature
0°C to 55°C
Storage Temperature
-20°C to 70°C
Dimensions
Approx. 282 × 423 × 112 mm
Weight
Approx. 3.0–3.5 kg
Recommended Related Models
Model
Description
2711-B6C10
PanelView 600 standard color HMI
2711-B5A1
PanelView 550 compact terminal
2711-T6C10
Touch-only PanelView 600 variant
2711P-T6C20D8
PanelView Plus 600 (modern upgrade)
2711P-T10C4D8
PanelView Plus 1000 HMI
2711-NL5
Replacement backlight module
2711-NC13
Programming/serial communication cable
1769-L24ER-QB1B
CompactLogix controller
Popular Allen Bradley Automation Products
Model
Product Category
1756-L81E
ControlLogix CPU
1769-IF8
Analog Input Module
5069-OB16
Digital Output Module
1734-AENTR
POINT I/O Ethernet Adapter
2711P-T7C4D8
PanelView Plus 700
20G11NC072JA0NNNNN
PowerFlex 755 Drive
1606-XLE240E
Industrial Power Supply
1794-IE8
FLEX I/O Analog Module
Industrial Applications
The Allen Bradley 2711-B6C16 is widely used in legacy industrial automation systems where stable HMI interaction and simple operator control are required.
Typical applications include:
Conveyor and material handling systems
Packaging machinery
Pump and motor control panels
HVAC systems
Water treatment plants
Food and beverage production lines
Textile machines
Small-scale process automation
OEM equipment panels
Retrofit industrial control systems
Its RS-232 and DeviceNet-based communication structure makes it suitable for older Allen-Bradley PLC ecosystems still operating in long-life industrial installations.
Key Advantages
Proven Legacy Reliability
The PanelView 600 series is known for long-term operational stability in harsh industrial environments with minimal failure rates.
Dual Control Interface
Combination of touchscreen and keypad allows flexible operation in environments where gloves or fast input changes are required.
Strong PLC Compatibility
Designed for integration with SLC 500, PLC-5, and MicroLogix systems using DF1/DH-485 communication protocols.
Rugged Industrial Construction
Built for vibration resistance, electrical noise immunity, and continuous-duty operation in factory environments.
Simple Maintenance and Serviceability
Replaceable backlight and modular hardware design reduce downtime and maintenance complexity.
Cost-Effective System Support
Ideal for extending the life of existing automation systems without requiring full migration to modern HMI platforms.
Technical FAQs
1. What is the Allen Bradley 2711-B6C16 used for?
It is an HMI terminal used for machine control, monitoring, and operator interaction in industrial automation systems.
2. What display does it use?
It uses a 5–5.7 inch color LCD display with 320 × 234 resolution.
3. What communication protocols are supported?
It supports RS-232-based DF1 or DH-485 (depending on configuration) and printer/download serial communication.
4. Is the 2711-B6C16 still manufactured?
No, it is a discontinued legacy product.
5. What software is used for programming?
It is programmed using PanelBuilder32 software.
6. Can it connect to Ethernet networks?
No, it is limited to serial-based communication and does not support Ethernet.
7. What PLCs is it compatible with?
Commonly used with SLC 500, PLC-5, and MicroLogix controllers.
8. What is the input voltage range?
It operates on 85–264V AC power.
9. Is it suitable for modern automation systems?
Not directly; it is mainly used in legacy systems unless upgraded via gateway solutions.
10. What is a modern replacement for this model?
Typical upgrades include PanelView Plus 600/700/1000 series HMIs or newer PanelView 800/Plus 7 platforms.
