Allen Bradley 1783-BMS06SL Stratix 5700 Ethernet Managed Switch
Allen Bradley 1783-BMS06SL Stratix 5700 Ethernet Managed Switch
0.0
Points
Brand:Allen Bradley PLC Item No.:1783-BMS06SL Product Origin:USA Product Dimensions:129.5 x 74.8 x 116.7 mm Product Weight:1.11 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Allen Bradley 1783-BMS06SL Stratix 5700 is a managed industrial Ethernet switch designed to provide reliable and structured network communication in automation environments. It is part of the Stratix 5700 family, widely used in Rockwell-based industrial networks for connecting controllers, drives, and distributed I/O systems.
Technical Specifications
Parameter
Specification
Product Type
Managed Ethernet Switch
Series
Stratix 5700
Model
1783-BMS06SL
Ports
4 × 10/100 Mbps RJ45 + 2 × SFP combo ports
Switching Layer
Layer 2
Mounting Type
DIN rail
IP Rating
IP30
Power Input
12–60 V DC (typical industrial range)
Operating Temperature
-40°C to 60°C (typical industrial range)
Dimensions
129.5 × 74.8 × 116.7 mm
Weight
1.11 kg
Recommended Related Models
Model
Product Name
1783-BMS10CGL
Allen Bradley Stratix 5700 10-Port Managed Switch
1783-BMS20CGL
Allen Bradley Stratix 5700 Advanced Managed Switch
1783-BMS04T4E2CG
Allen Bradley Stratix 5700 Compact Ethernet Switch
1783-CMS6B
Allen Bradley Stratix 5700 Replacement Managed Switch
Popular Related Models
Model
Product Name
1783-US06T
Allen Bradley Stratix 2000 Unmanaged Switch
1783-US08T
Allen Bradley Stratix 2000 Ethernet Switch
1783-SFP1GSX
Allen Bradley Gigabit SFP Module
1783-SFP1GLX
Allen Bradley Long-Range SFP Transceiver
Applications
• Industrial Ethernet communication backbone for PLC-5 / CompactLogix hybrid networks
• Machine-level network segmentation for automation cells and production lines
• Data exchange between controllers, HMI systems, drives, and remote I/O modules
• Integration of industrial devices using managed switching with traffic prioritization
• Factory network infrastructure requiring deterministic and stable Ethernet communication
• Retrofit upgrades from unmanaged switches to managed Stratix industrial networking
• Multi-device control systems in packaging, automotive, and process automation environments
Advantages
• Managed Layer 2 switching improves network stability and communication control
• Industrial-grade design supports harsh electrical noise and temperature environments
• Flexible copper and SFP fiber port combination enables scalable network architecture
• Supports advanced diagnostics for faster fault detection and maintenance
• Compact DIN-rail mounting saves cabinet space in control panels
• Strong integration capability within Rockwell Automation ecosystems
Technical FAQs
Q1: What is the main function of the 1783-BMS06SL?
It is a managed industrial Ethernet switch used to connect and control communication between automation devices.
Q2: Does it support Layer 3 routing?
No, it operates primarily as a Layer 2 managed switch.
Q3: How many ports does it have?
It typically provides 4 copper Ethernet ports and 2 combination SFP ports.
Q4: Can it be used as an unmanaged switch?
Yes, it can operate with default settings similar to an unmanaged switch, but advanced features require configuration.
Q5: Is it suitable for industrial environments?
Yes, it is designed for industrial applications with resistance to vibration, noise, and temperature variation.
Q6: Does it support fiber connections?
Yes, via its SFP slots for fiber uplink or long-distance communication.
Q7: Can it integrate with Rockwell PLC systems?
Yes, it is optimized for integration with Rockwell Automation architectures.
Q8: Does it support VLAN configuration?
Yes, VLAN segmentation is supported through managed settings.
Q9: What mounting method is used?
DIN rail mounting is standard for industrial control cabinets.
Q10: Is it still actively produced?
Some variants have been marked as discontinued or legacy depending on firmware and revision.
