Allen Bradley 1783-BMS10CGP Stratix 5700 Ethernet Managed Switch
Allen Bradley 1783-BMS10CGP Stratix 5700 Ethernet Managed Switch
0.0
Points
Brand:Allen Bradley PLC Item No.:1783-BMS10CGP Product Origin:USA Product Dimensions:135.8 x 91.4 x 129.5 mm Product Weight:1.38 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Allen Bradley 1783-BMS10CGP Stratix 5700 is a managed industrial Ethernet switch designed to deliver reliable and secure communication across automation networks. Developed in collaboration with Cisco, it combines industrial-grade hardware with enterprise networking capabilities to support demanding factory-floor applications.
In automation environments, this switch is often deployed to improve network determinism, enable device segmentation, and support advanced protocols such as CIP Sync and Device Level Ring. Although now discontinued, it remains widely installed in existing Rockwell Automation infrastructures where stable Ethernet communication is essential.
Technical Specifications
Parameter
Specification
Product Type
Managed Ethernet Switch
Series
Stratix 5700
Model
1783-BMS10CGP
Total Ports
10
Copper Ports
8 × 10/100 Mbps RJ45
Combo Ports
2 × 10/100/1000 Mbps RJ45/SFP
Switching Layer
Layer 2
Power Input
12–48 V DC
Mounting Type
DIN rail
Operating Temperature
-40°C to 60°C
Dimensions
135.8 × 91.4 × 129.5 mm
Weight
1.38 kg
Recommended Related Models
Model
Product Name
1783-BMS10CGP
Allen Bradley Stratix 5700 10-Port Managed Switch (same family variant)
1783-BMS06SL
Allen Bradley Stratix 5700 Compact Managed Switch
1783-BMS20CGL
Allen Bradley Stratix 5700 Advanced Managed Switch
1783-CMS10DP
Allen Bradley Stratix 5200 Managed Ethernet Switch (replacement series)
Popular Related Models
Model
Product Name
1783-US06T
Allen Bradley Stratix 2000 Unmanaged Switch
1783-US08T
Allen Bradley Stratix 2000 Ethernet Switch
1783-SFP1GSX
Allen Bradley Gigabit SFP Module
1783-SFP1GLX
Allen Bradley Long Range Fiber SFP Transceiver
Applications
• Industrial Ethernet backbone for PLC-based automation networks and distributed control systems
• High-availability communication between PLCs, drives, HMIs, and remote I/O devices
• Factory-wide network segmentation using VLANs for multi-machine production environments
• Time-synchronized automation systems using CIP Sync (IEEE 1588 PTP)
• Device Level Ring (DLR) architectures for redundant industrial network topologies
• Retrofit replacement for unmanaged switches in legacy production lines
• Secure plant-floor communication infrastructure in automotive, packaging, and process industries
• Supports advanced Layer 2 management features including VLAN, QoS, and port control
• Built-in industrial robustness designed for vibration, noise, and harsh electrical environments
• Integrated diagnostics improve fault detection and reduce downtime during maintenance
• Supports CIP Sync and DLR for deterministic and redundant automation networking
• Compact DIN-rail design optimizes control cabinet space usage
Technical FAQs
Q1: What is the main function of the 1783-BMS10CGP?
It is a managed industrial Ethernet switch used to connect and control communication between automation devices in industrial networks.
Q2: Is this switch Layer 2 or Layer 3?
It operates primarily as a Layer 2 managed switch.
Q3: How many ports does it support?
It provides 10 ports: 8 Fast Ethernet copper ports and 2 gigabit combo ports (RJ45 or SFP).
Q4: Does it support redundancy features?
Yes, it supports Device Level Ring (DLR) for network redundancy.
Q5: Can it handle VLAN configuration?
Yes, VLAN segmentation is supported for network isolation and traffic management.
Q6: Is it still in production?
No, it has been officially discontinued, with replacement models available.
Q7: What is the recommended replacement model?
Rockwell Automation recommends newer Stratix 5700/5200 series replacements depending on system design.
Q8: Does it support industrial time synchronization?
Yes, it supports CIP Sync based on IEEE 1588 Precision Time Protocol.
Q9: Can it be used in unmanaged mode?
Yes, it can operate with default settings similar to an unmanaged switch, but advanced features require configuration.
Q10: What industries commonly use this switch?
It is widely used in manufacturing, automotive, packaging, and process automation systems.
