Brand:Ovation DCS Item No.:OVATION 1X00163H01 Product Origin:USA Product Dimensions:133 × 45 × 250 mm Product Weight:3.5 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Ovation 1X00163H01 is an Emerson Ovation Distributed Control System (DCS) plug-in style I/O power supply module designed to deliver stable and regulated power to Ovation I/O racks and field interface electronics. It is commonly used in power generation plants, water treatment facilities, and heavy industrial process environments where continuous and reliable DC power distribution is essential for system stability.
This module is typically identified as a Magnetek WH3A-2DF-based power supply unit, used within Ovation I/O architectures to support controller-side and field-side power requirements in modular rack systems.
Technical Specifications
Specification
Details
Manufacturer
Emerson (Ovation DCS) / Magnetek OEM
Product Series
Ovation I/O Power System
Part Number
1X00163H01
Module Type
Plug-in I/O Power Supply Module
Input Type
AC Input (system-dependent configuration)
Output Type
13V / 24V DC regulated (typical configuration)
Output Function
Powers Ovation I/O modules and field interface circuits
Protection Features
Overload, short-circuit, and thermal protection
Installation
Plug-in rack-mounted module
System Role
Distributed I/O power distribution
Physical Dimensions & Weight
Parameter
Value
Dimensions (H × W × D)
approx. 133 × 45 × 250 mm
Weight
approx. 2.5–3.5 kg
Recommended Related Models
Model
Description
1X00163H02
48V DC I/O power supply variant
1X00163H03
DC input power supply version
1X00163H04
Alternate 48V configuration module
1X00097H01
System main power supply module
1X00024H01
Ovation central power supply unit
1X00093G10
Ethernet switch module
1X00133H01
Fast Ethernet NIC module
Popular Ovation Power & System Modules
Model
Function
1X00163H01
I/O Power Supply Module
1X00163H02
High-voltage Power Variant
1X00163H03
DC Input Power Module
1X00097H01
System Power Supply
1X00024H01
Central Power Unit
1X00095H01
Network Switch Module
1C31113G05
Analog Input Module
Industrial Applications
The Ovation 1X00163H01 is used in distributed control system environments where stable power delivery to I/O subsystems is critical for continuous plant operation.
Typical applications include:
Thermal power generation systems
Nuclear auxiliary control systems
Hydroelectric control infrastructure
Water and wastewater treatment plants
Petrochemical and refinery automation systems
Industrial boiler and turbine control systems
Utility SCADA and grid monitoring networks
Large-scale DCS I/O cabinet power distribution
Key Advantages
Stable I/O Power Distribution
Provides reliable DC power to Ovation I/O modules and field interfaces.
Plug-In Modular Design
Enables fast replacement and maintenance without system redesign.
Industrial-Grade Protection
Built-in safeguards against overload, short circuit, and thermal stress.
OEM-Integrated Architecture
Based on Magnetek WH3A series design for Ovation compatibility.
High System Reliability
Supports continuous operation in mission-critical industrial environments.
Long Lifecycle Utility Deployment
Widely used in long-term installed base power systems.
Technical FAQs
1. What is the Ovation 1X00163H01 used for?
It is used as a plug-in I/O power supply module in Emerson Ovation DCS systems.
2. What does it power?
It supplies DC power to Ovation I/O modules and field interface electronics.
3. What is its output voltage?
Typically provides 13V and/or 24V DC depending on configuration.
4. Is it a standalone power supply?
No. It is designed for integration into Ovation I/O racks.
5. What are its dimensions?
Approximately 133 × 45 × 250 mm (H × W × D).
6. What is its weight?
Approximately 2.5–3.5 kg.
7. What is its OEM origin?
It is associated with Magnetek WH3A-2DF plug-in power supply design.
8. Where is it commonly used?
Power plants, utilities, petrochemical facilities, and industrial automation systems.
9. Does it support protection features?
Yes, including overload, short-circuit, and thermal protection.
10. Why is it important in Ovation systems?
Because it ensures stable and continuous power delivery to I/O subsystems in mission-critical control environments.
