Brand:Ovation DCS Item No.:OVATION 1X00163H02 Product Origin:USA Product Dimensions:133 × 45 × 250 mm Product Weight:3.6 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Ovation 1X00163H02 is an Emerson Ovation Distributed Control System (DCS) I/O power supply module variant, designed to provide regulated DC power for Ovation I/O racks and field interface electronics. It is commonly deployed in industrial environments such as power plants, water treatment systems, and petrochemical facilities where stable, redundant, and continuous power delivery is essential for control system integrity.
This module is part of the Ovation modular power architecture and is typically used as an alternative voltage or configuration variant within the WH3-series plug-in power supply family, ensuring compatibility across different cabinet designs and system generations.
Technical Specifications
Specification
Details
Manufacturer
Emerson (Ovation DCS) / Magnetek OEM
Product Series
Ovation I/O Power System
Part Number
1X00163H02
Module Type
I/O Power Supply Module (variant)
Input Type
AC input (system-dependent)
Output Type
Regulated DC output (typically 24V / system variant dependent)
Output Function
Powers Ovation I/O modules and interface circuits
Protection Features
Overload, short-circuit, thermal protection
Installation
Plug-in rack-mounted module
System Role
Distributed I/O power distribution
Physical Dimensions & Weight
Parameter
Value
Dimensions (H × W × D)
approx. 133 × 45 × 250 mm
Weight
approx. 2.6–3.6 kg
Recommended Related Models
Model
Description
1X00163H01
I/O power supply module (standard variant)
1X00163H03
DC input power supply version
1X00163H04
Extended configuration variant
1X00097H01
Main system power supply module
1X00024H01
Central Ovation power supply unit
1X00095H01
Ethernet switch module
1C31113G05
Analog input module
Popular Ovation Power Modules
Model
Function
1X00163H02
I/O Power Supply Variant Module
1X00163H01
Standard I/O Power Supply
1X00163H03
DC Input Power Module
1X00097H01
System Power Supply
1X00024H01
Central Power Unit
1X00093G10
Network Switch Module
1C31116G01
Analog Output Module
Industrial Applications
The Ovation 1X00163H02 is used in distributed control environments where stable I/O power is required to maintain uninterrupted automation performance.
Typical applications include:
Thermal power generation plants
Nuclear auxiliary control systems
Hydroelectric power stations
Water and wastewater treatment facilities
Petrochemical processing plants
Refinery control systems
Industrial boiler and turbine automation
Utility SCADA infrastructure systems
Large-scale Ovation DCS I/O cabinets
Key Advantages
Stable I/O Power Delivery
Ensures continuous and regulated power supply to Ovation I/O modules.
Modular Plug-In Design
Allows fast maintenance and replacement without system downtime.
Industrial Protection Features
Built-in safeguards against overload, short circuit, and thermal stress.
System-Level Compatibility
Designed for seamless integration into Ovation WH3-series power architectures.
High Reliability for Critical Infrastructure
Supports continuous operation in utility-grade environments.
Flexible Configuration Variant
Provides compatibility across different Ovation cabinet designs and revisions.
Technical FAQs
1. What is the Ovation 1X00163H02 used for?
It is used as a plug-in I/O power supply module in Emerson Ovation DCS systems.
2. Is it the same as 1X00163H01?
It is a variant version, typically used for different configurations or output requirements within the same WH3-series family.
3. What does it power?
It supplies DC power to Ovation I/O modules and field interface electronics.
4. What is its output voltage?
Typically 24V DC (exact output depends on system configuration).
5. What are its dimensions?
Approximately 133 × 45 × 250 mm (H × W × D).
6. What is its weight?
Approximately 2.6–3.6 kg.
7. Is it a standalone power supply?
No, it is designed for integration into Ovation I/O racks.
8. Where is it commonly used?
Power plants, utilities, petrochemical facilities, and industrial automation systems.
9. Does it support protection features?
Yes, including overload, short-circuit, and thermal protection.
10. Why is it important in Ovation systems?
Because it ensures stable and continuous power delivery to distributed I/O subsystems in mission-critical control environments.
