Brand:Ovation DCS Item No.:OVATION 1X00163H03 Product Origin:USA Product Dimensions:133 × 45 × 250 mm Product Weight:3.6 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Ovation 1X00163H03 is an Emerson Ovation Distributed Control System (DCS) plug-in I/O power supply module designed for industrial control cabinets requiring stable DC-powered distribution to Ovation I/O subsystems. It is part of the WH3-series power module family and is typically deployed in environments where DC input power architecture is preferred over AC input configurations.
This module is widely used in power plants, utilities, petrochemical facilities, and heavy industrial automation systems, ensuring continuous and regulated power delivery to I/O racks, field interface electronics, and system modules within the Ovation architecture.
Technical Specifications
Specification
Details
Manufacturer
Emerson (Ovation DCS) / Magnetek OEM
Product Series
Ovation I/O Power System
Part Number
1X00163H03
Module Type
Plug-in I/O Power Supply Module
Input Type
DC Input
Output Type
Regulated DC output (system-dependent, typically 13V / 24V)
Output Function
Powers Ovation I/O modules and interface circuits
Protection Features
Overload, short-circuit, thermal protection
Installation
Rack-mounted plug-in module
System Role
Distributed I/O power distribution
Physical Dimensions & Weight
Parameter
Value
Dimensions (H × W × D)
approx. 133 × 45 × 250 mm
Weight
approx. 2.6–3.6 kg
Recommended Related Models
Model
Description
1X00163H01
AC input I/O power supply module
1X00163H02
AC input variant (alternate voltage configuration)
1X00163H04
DC input high-voltage variant
1X00097H01
System main power supply module
1X00024H01
Central Ovation power supply unit
1X00093G10
Ethernet switch module
1C31113G05
Analog input module
Popular Ovation Power Modules
Model
Function
1X00163H03
DC Input I/O Power Module
1X00163H01
AC Input I/O Power Module
1X00163H02
AC Variant Power Module
1X00163H04
High-Voltage DC Variant
1X00097H01
System Power Supply
1X00024H01
Central Power Unit
1C31116G01
Analog Output Module
Industrial Applications
The Ovation 1X00163H03 is used in distributed control environments where DC-powered infrastructure is required for stable and efficient I/O system operation.
Typical applications include:
Thermal power generation plants
Nuclear auxiliary control systems
Hydroelectric power stations
Water and wastewater treatment facilities
Petrochemical processing plants
Refinery automation systems
Industrial boiler and turbine control systems
Utility SCADA infrastructure networks
Large-scale Ovation DCS I/O cabinet systems
Key Advantages
DC Input Power Architecture
Designed for systems that rely on DC power distribution for enhanced stability and flexibility.
Stable I/O Power Delivery
Ensures continuous power supply to Ovation I/O modules and field interfaces.
Modular Plug-In Design
Allows fast replacement and simplified maintenance in control cabinets.
Industrial Protection System
Built-in protection against overload, short circuit, and thermal stress.
High System Reliability
Suitable for continuous 24/7 operation in mission-critical environments.
OEM-Grade Compatibility
Based on Magnetek WH3-series design architecture for Ovation systems.
Technical FAQs
1. What is the Ovation 1X00163H03 used for?
It is used as a DC input I/O power supply module in Emerson Ovation DCS systems.
2. What is the main difference from 1X00163H01?
1X00163H03 uses DC input power, while 1X00163H01 typically uses AC input.
3. What does it power?
It supplies regulated DC power to Ovation I/O modules and system interfaces.
4. What is the output voltage?
Typically 13V and/or 24V DC depending on system configuration.
5. What are its dimensions?
Approximately 133 × 45 × 250 mm (H × W × D).
6. What is its weight?
Approximately 2.6–3.6 kg.
7. Is it a standalone device?
No, it is designed for integration into Ovation I/O racks.
8. Where is it commonly used?
Power plants, utilities, petrochemical, and industrial automation systems.
9. Does it support protection features?
Yes, including overload, short-circuit, and thermal protection.
10. Why is it important in Ovation systems?
Because it ensures stable DC-powered operation of I/O subsystems in critical industrial control environments.
