Brand:Ovation DCS Item No.:OVATION 1X00416H04 Product Origin:USA Product Dimensions:102 × 102 × 178 mm Product Weight:3.6 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Ovation 1X00416H04 is an Emerson Ovation Distributed Control System (DCS) power supply module variant designed to provide regulated DC power for Ovation system racks and I/O subsystems. It belongs to the WH5/WH-series power architecture used in industrial automation environments where stable, redundant, and long-life power delivery is essential.
This module is typically deployed in power generation plants, water treatment facilities, petrochemical sites, and large-scale process industries, supporting continuous operation of Ovation controllers, I/O modules, and communication interfaces.
The 1X00416H04 is generally considered a configuration or revision variant within the 1X00416 power supply family, optimized for specific cabinet layouts or output requirements in Ovation installations.
Technical Specifications
Specification
Details
Manufacturer
Emerson (Ovation DCS)
Product Series
Ovation Power System (WH5 family)
Part Number
1X00416H04
Module Type
System / I/O Power Supply Module
Input Type
AC input (industrial control supply)
Output Type
Regulated DC output (system-dependent, typically 24V auxiliary class)
Function
Powers Ovation I/O and system electronics
Protection Features
Overload, short-circuit, thermal protection
Installation
Rack-mounted / cabinet-integrated module
System Role
Distributed power support for Ovation architecture
Physical Dimensions & Weight
Parameter
Value
Dimensions (H × W × D)
approx. 102 × 102 × 178 mm
Weight
approx. 3.4–3.6 kg
Recommended Related Models
Model
Description
1X00416H01
Standard WH5-2FF power supply module
1X00416H03
Alternate power supply variant
1X00163H01
I/O power supply module
1X00097H01
Main system power supply module
1X00024H01
Central Ovation power unit
1X00095H01
Ethernet switch module
1C31113G05
Analog input module
Popular Ovation Power Modules
Model
Function
1X00416H04
Power Supply Module Variant
1X00416H01
Standard Power Supply
1X00416H03
Alternative Configuration Version
1X00163H01
I/O Power Module
1X00097H01
System Power Supply
1X00024H01
Central Power Unit
1C31116G01
Analog Output Module
Industrial Applications
The Ovation 1X00416H04 is used in mission-critical environments where stable DC power is required for distributed control system operation.
Typical applications include:
Thermal power generation plants
Nuclear auxiliary control systems
Hydroelectric power stations
Water and wastewater treatment facilities
Petrochemical and refinery automation systems
Industrial boiler and turbine control systems
Utility SCADA and grid infrastructure
Large-scale Ovation DCS control cabinets
It ensures uninterrupted power delivery to critical control and I/O hardware in continuous-process industries.
Key Advantages
Stable Industrial Power Output
Provides regulated DC power for Ovation system stability.
Modular WH-Series Architecture
Designed for plug-in integration in Ovation control cabinets.
High Reliability Operation
Suitable for continuous 24/7 industrial environments.
Built-In Electrical Protection
Includes overload, short-circuit, and thermal protection functions.
OEM System Compatibility
Part of the Emerson WH5/WH-series power family used in Ovation platforms.
Long Lifecycle Industrial Design
Engineered for extended deployment in utility-grade systems.
Technical FAQs
1. What is the Ovation 1X00416H04 used for?
It is used as a power supply module within Emerson Ovation DCS systems.
2. Is it a standalone power supply?
No, it is designed for integration into Ovation control racks or cabinets.
3. What does it power?
It powers Ovation I/O modules, controllers, and system electronics.
4. What is its output type?
Regulated DC output, typically in the 24V auxiliary power range depending on configuration.
5. What are its dimensions?
Approximately 102 × 102 × 178 mm (H × W × D).
6. What is its weight?
Approximately 3.4–3.6 kg.
7. What is its role in a DCS system?
It ensures stable and continuous power distribution across Ovation subsystems.
8. What industries use it?
Power generation, utilities, petrochemical, and industrial automation sectors.
9. Does it include protection features?
Yes, including overload, short-circuit, and thermal protection.
10. Why is it important in Ovation systems?
Because stable power is fundamental to maintaining reliable operation of the entire DCS architecture.
