OVATION 5A26304G02 Power Distribution / Digital Output Panel Module
OVATION 5A26304G02 Power Distribution / Digital Output Panel Module
0.0
Points
Brand:Ovation DCS Item No.:OVATION 5A26304G02 Product Origin:USA Product Dimensions:160 × 160 × 120 mm Product Weight:1.2 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Ovation 5A26304G02 is an Emerson Ovation Distributed Control System (DCS) power distribution and digital output panel module designed to manage and switch industrial field loads within control cabinet architectures. It is commonly used in power generation plants, utilities, and heavy industrial automation systems, where reliable load switching and field device control are critical.
Based on its typical application within the Ovation ecosystem, this module is associated with high-voltage DC load switching (up to 60 VDC) and is often used for driving relays, lamps, solenoids, and other moderate industrial loads in distributed control environments.
Typically 16 output points (configuration dependent)
Load Type
Relays, lamps, solenoids, industrial control devices
System Role
Field load switching and power distribution interface
Installation
Control cabinet / Ovation I/O panel integration
Physical Dimensions & Weight
Parameter
Value
Dimensions (H × W × D)
approx. 160 × 160 × 120 mm
Weight
approx. 0.9–1.2 kg
Recommended Related Models
Model
Description
1C31122G01
Ovation digital output module
1C31174G03
0–20 mA loop interface module
1C31125G01
Ovation I/O module variant
3A99200G01
PCI backplane module
1X00093G10
Ethernet switch module
1X00095H01
Network switch module
1X00188H01
Analog output module
Popular Ovation I/O & Output Modules
Model
Function
5A26304G02
Power Distribution / Digital Output Panel
1C31122G01
Digital Output Module
1C31174G03
Analog Loop Interface Module
1C31113G05
Analog Input Module
1C31116G01
Analog Output Module
1X00093G07
System Interface Module
1X00163H01
I/O Power Supply Module
Industrial Applications
The Ovation 5A26304G02 is used in industrial automation systems where reliable switching of electrical loads is required for safe and efficient plant operation.
Typical applications include:
Thermal power generation control systems
Nuclear auxiliary switching systems
Hydroelectric plant automation
Water and wastewater treatment systems
Petrochemical and refinery control systems
Industrial boiler and turbine control
SCADA-based utility automation networks
Large-scale distributed control system (DCS) installations
It is especially useful in applications requiring multi-channel output control for field devices.
Key Advantages
High-Capacity Load Switching
Supports multiple industrial output channels for flexible field device control.
60 VDC Industrial Load Capability
Suitable for relays, solenoids, lamps, and moderate-power field loads.
Robust Industrial Design
Built for continuous operation in harsh electrical environments.
DCS Integration Compatibility
Works within Emerson Ovation distributed control architectures.
Multi-Channel Control Efficiency
Reduces wiring complexity by consolidating output functions.
Proven Utility Industry Deployment
Widely used in power and process industries with long lifecycle systems.
Technical FAQs
1. What is the Ovation 5A26304G02 used for?
It is used as a power distribution and digital output panel module in Ovation DCS systems.
2. What is its main function?
It switches and distributes electrical signals to field devices such as relays and actuators.
3. What voltage does it support?
It typically supports switching up to 60 VDC loads.
4. How many outputs does it have?
Commonly configured with around 16 output channels (variant dependent).
5. What are its dimensions?
Approximately 160 × 160 × 120 mm (H × W × D).
6. What is its weight?
Approximately 0.9–1.2 kg.
7. Is it a standalone device?
No, it is designed for integration into Ovation control cabinet systems.
8. What industries use it?
Power generation, utilities, petrochemical, water treatment, and heavy industry.
9. Does it use relays or transistors?
It may use current-sinking transistor outputs or relay-based switching depending on configuration.
10. Why is it important in Ovation systems?
Because it provides reliable multi-channel switching control for industrial field devices within the DCS architecture.
