Allen Bradley 1794-TB3T Flex I/O Terminal Base Unit
Allen Bradley 1794-TB3T Flex I/O Terminal Base Unit
0.0
Points
Brand:Allen Bradley PLC Item No.:1794-TB3T Product Origin:USA Product Dimensions:94 x 94 x 69 mm Product Weight:0.2 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Allen-Bradley 1794-TB3T Flex I/O Terminal Base Unit is a specialized component within the Flex I/O ecosystem, designed to support temperature and thermocouple-based industrial applications. It provides a structured and reliable interface between field wiring and I/O modules, ensuring accurate signal transmission in demanding process environments.
With its screw-clamp design and modular architecture, the TB3T simplifies installation while maintaining high signal integrity. It is widely used in process industries where precise temperature measurement is critical, such as manufacturing, energy production, and thermal processing systems.
Technical Specifications
Parameter
Specification
Product Model
1794-TB3T
Product Type
Flex I/O Terminal Base Unit
Brand
Allen-Bradley
Function
Field wiring termination for temperature / thermocouple modules
System Compatibility
Flex I/O distributed I/O systems
Termination Type
Screw-clamp
Signal Support
Analog / temperature inputs (module dependent)
Mounting
DIN rail / panel mount
Dimensions
94 × 94 × 69 mm
Weight
0.2 kg
Applications
The Allen-Bradley 1794-TB3T Flex I/O Terminal Base Unit is designed as a specialized wiring interface within the Flex I/O family, typically used in temperature measurement and thermocouple-based industrial control systems. It provides reliable field termination and signal routing for modular I/O architectures.
Typical applications include:
Industrial temperature monitoring systems
Thermocouple-based process control
PLC-based distributed I/O systems
Manufacturing and process automation
Power generation monitoring systems
Furnace and heat treatment control systems
HVAC and environmental monitoring systems
Flexible industrial signal termination in control panels
Advantages
Designed specifically for thermocouple and temperature input applications
Screw-clamp termination ensures strong and stable field wiring connections
High resistance to vibration and industrial electrical noise
Modular Flex I/O design allows easy system expansion and maintenance
Supports both analog and digital module integration depending on configuration
Improves wiring organization in temperature-heavy applications
Reduces installation time in complex control systems
Enhances long-term signal stability and measurement reliability
Compatible with Allen-Bradley Flex I/O architecture
Industrial-grade durability for continuous operation environments
Technical FAQs
1. What is the main function of the 1794-TB3T?
It serves as a terminal base unit for Flex I/O modules, specifically optimized for temperature and thermocouple applications.
2. Is it only used for temperature measurement systems?
Primarily yes, but it can support other Flex I/O modules depending on system configuration.
3. What type of termination method does it use?
It uses screw-clamp terminals for secure and vibration-resistant wiring.
4. Does it support analog and digital modules?
Yes, depending on the installed Flex I/O module type.
5. What makes it different from standard TB3 bases?
It includes specific wiring arrangements suitable for thermocouple and temperature input modules.
6. Can it be used in PowerFlex systems?
It can be used in broader automation systems that integrate with PLCs and drives, including PowerFlex environments indirectly.
7. Is it suitable for harsh environments?
Yes, it is designed for industrial conditions with vibration, heat, and electrical noise.
8. Does it require special calibration?
No calibration is required at the base level; calibration is handled at the I/O module level.
9. Can modules be replaced without rewiring?
Yes, Flex I/O design allows module replacement while keeping field wiring intact.
10. Why is a dedicated terminal base important in temperature applications?
Because it ensures stable, low-noise signal routing for sensitive thermocouple measurements.
