Overview

The Honeywell CC-PCNT05 Analog Input Module offers a compact, reliable solution for integrating multiple analog signals into your automation network. Its precise signal handling, combined with flexible mounting options and robust construction, ensures efficient monitoring and control in demanding industrial applications. Whether retrofitting existing systems or designing new installations, the CC-PCNT05 enhances operational accuracy and reliability.

Technical Specifications

Feature	Specification
Dimensions	120 mm × 90 mm × 35 mm
Weight	0.25 kg
Input Channels	8 analog inputs
Signal Types	4–20 mA, 0–10 V
Power Supply	24 VDC
Mounting	DIN rail or panel mount
Operating Temperature	-20°C to +60°C (-4°F to +140°F)
Isolation	Channel-to-channel isolation
Response Time	<10 ms per channel
Diagnostics	LED indicators and error detection

Recommended Related Models

Honeywell CC-PCNT04 Analog Input Module
Honeywell CC-PDO02 Digital Output Module
Honeywell CC-PCI01 Signal Conditioning Module

Popular Related Models

Honeywell UDC3200 Universal Digital Controller
Honeywell HC900 Control System Modules
Honeywell Fieldbus H1 Transmitters

Applications

The Honeywell CC-PCNT05 Analog Input Module is designed for precision monitoring of analog signals in process automation systems. It is ideal for integrating temperature, pressure, and flow sensors into Honeywell or third-party control platforms. Perfect for chemical plants, power generation, and manufacturing facilities, it enables accurate data collection and seamless communication with control systems.

Benefits

High-Precision Signal Acquisition: Captures analog inputs with exceptional accuracy for reliable process control.
Compact & Lightweight: Small footprint allows flexible installation in confined control panels.
Fast Response: Real-time signal processing ensures timely decision-making.
Seamless Integration: Fully compatible with Honeywell CC-series controllers and field devices.
Durable Build: Designed to withstand industrial environmental conditions, ensuring longevity.

Technical FAQs

What types of analog signals are supported?
Supports 4–20 mA and 0–10 V analog inputs.
What is the module’s operating temperature range?
-20°C to +60°C (-4°F to +140°F).
How is the module mounted?
DIN rail or panel mount compatible.
Does it support signal isolation?
Yes, each channel is electrically isolated to prevent cross-talk.
How many input channels are available?
Supports up to 8 analog input channels.
What is the power requirement?
Operates on 24 VDC industrial power supply.
Can it be used in hazardous locations?
Suitable for standard industrial environments; check local certifications for hazardous areas.
Are diagnostics available?
LED status indicators and error detection for each input channel.
What is the typical response time?
Less than 10 milliseconds per channel.
Is firmware upgradable?
Yes, firmware updates are supported through Honeywell configuration software.
