The Emerson VE6001P1 is a DeltaV system Ethernet communication hub designed to support high-speed network connectivity across industrial automation environments. As part of the DeltaV M-series communication infrastructure, it provides reliable 10Base-T Ethernet distribution for controllers, workstations, and distributed I/O systems.
Engineered for stable data transmission in process-critical applications, the VE6001P1 ensures consistent network performance even under heavy industrial electrical noise. It plays a key role in maintaining deterministic communication between DeltaV system components, enabling smooth data flow across control networks.
This module is widely used in legacy and hybrid DeltaV architectures where robust Ethernet connectivity and system interoperability are required.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Emerson |
| Model | VE6001P1 |
| Product Type | Ethernet Hub / Communication Module |
| System Platform | DeltaV Distributed Control System |
| Ethernet Ports | 8 × 10Base-T RJ45 |
| Data Rate | 10 Mbps |
| Network Type | Industrial Ethernet (Legacy DeltaV architecture) |
| Communication Function | Hub-based signal distribution |
| Protocol Support | Ethernet-based DeltaV system communication |
| Power Supply | 24 VDC system power |
| Power Consumption | Low-power industrial design (~3–5 W) |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -20°C to +70°C |
| Humidity | 5%–95% non-condensing |
| EMC Protection | Industrial noise immunity design |
| Mounting Type | DIN rail / control cabinet installation |
| Indicators | Link / Activity LED per port |
| Dimensions (H × W × D) | 130 mm × 45 mm × 110 mm |
| Weight | ~0.45 kg |
Recommended System Integration Modules
For stable DeltaV communication architecture, VE6001P1 is typically used alongside:
| Module | Function |
|---|---|
| VE6006 | Ethernet media converter module |
| VE6015 Series | Fast Ethernet switch modules (10/100 Mbps) |
| VE6014 Series | Fiber optic Ethernet switch modules |
| VE5008 | System power redundancy module |
| VE4070 | System interface adapter |
| VE5056 | Digital I/O communication interface module |
These components form a reliable and scalable industrial communication backbone for DeltaV systems.
Popular Emerson DeltaV Communication Modules
Within Emerson’s automation portfolio, VE6001P1 belongs to the DeltaV communication and networking family, which includes:
- VE6001P1 8-Port Ethernet Hub Module
- VE6006 Ethernet Media Converter
- VE6014 Series Fiber Optic Switch Modules
- VE6015 Series Fast Ethernet Switch Modules
- VE6017 Series Industrial Ethernet Switches
- VE4001 Communication Interface Modules
- VE4070 System Interface Modules
- VE4201 Remote Communication Interface
These modules are designed to ensure deterministic communication and system-wide data integrity.
