The Emerson VE6014P4 is a DeltaV industrial fiber-optic Ethernet switch module designed to provide reliable, high-speed network communication within distributed control system (DCS) architectures. As part of the DeltaV Smart Switch family, it supports deterministic 100BASE-FX fiber networking, ensuring stable and noise-immune data transmission across controllers, operator stations, and remote I/O segments.
The “P4” variant typically represents a configuration or regional hardware revision within the VE6014 series, while maintaining the same core switching architecture used across VE6014P1–P4 modules. It is widely deployed in large-scale process automation environments where long-distance fiber communication and high electromagnetic immunity are required for uninterrupted plant operations.
Engineered for mission-critical industrial networks, the VE6014P4 supports robust Layer 2 switching performance, making it a key backbone component in DeltaV fiber-based control network topologies.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Emerson |
| Model | VE6014P4 |
| Product Type | Industrial Fiber Optic Ethernet Switch |
| System Platform | DeltaV Distributed Control System |
| Network Type | 100BASE-FX Fiber Ethernet |
| Data Rate | 100 Mbps Fast Ethernet |
| Port Configuration | Up to 24-port fiber switch architecture (system dependent) |
| Switching Layer | Layer 2 Ethernet switching |
| Media Type | Multimode fiber (industrial-grade FX standard) |
| Communication Role | DeltaV plant network backbone distribution |
| Power Supply | 24 VDC system power |
| Power Consumption | ~8–15 W typical industrial design |
| Redundancy Support | System-level redundancy via DeltaV architecture |
| Operating Temperature | 0°C to +60°C |
| Storage Temperature | -20°C to +70°C |
| Humidity | 5%–95% non-condensing |
| EMC Immunity | High industrial noise resistance design |
| Mounting Type | Rack / control cabinet installation |
| Status Indicators | Per-port Link/Activity LEDs |
| Fiber Connector Type | SC / ST (configuration dependent) |
| Dimensions (H × W × D) | ~130 mm × 440 mm × 250 mm |
| Weight | ~3.5–5.0 kg |
Recommended System Integration Modules
For a complete DeltaV communication infrastructure, VE6014P4 is typically integrated with:
| Module | Function |
|---|---|
| VE6014P1 | Base fiber switch platform variant |
| VE6014P2 | Alternate configuration variant |
| VE6014P3 | Regional or revision variant |
| VE6015 Series | Copper Fast Ethernet switch modules |
| VE6017 Series | Advanced industrial Ethernet switches |
| VE6018 Series | High-density fiber switch systems |
| VE6006 | Fiber-to-copper media converter module |
| VE6001P1 | Legacy Ethernet hub module |
| VE4070 | System interface and carrier module |
These modules collectively form a scalable, redundant, and high-availability DeltaV industrial communication backbone.
Popular Emerson DeltaV Communication Modules
Within Emerson’s DeltaV ecosystem, VE6014P4 belongs to the fiber Ethernet switching family, which includes:
- VE6014P1 / P2 / P3 / P4 Fiber Switch Variants
- VE6015 Series Fast Ethernet Switch Modules
- VE6017 Series Industrial Network Switches
- VE6018 High-Density Fiber Switch Platforms
- VE6021 Advanced Ethernet Switch Systems
- VE6006 Media Converter Modules
- VE6001P1 Ethernet Hub Modules
- VE4070 System Interface Modules
These modules are designed to ensure deterministic communication and high network availability in industrial automation environments.
