The Emerson SE4006P2 KJ3241X1-BK1 + KJ4006X1-BD1 is a complete DeltaV S-Series Serial Interface Module Assembly engineered to establish reliable communication between DeltaV Distributed Control Systems (DCS) and third-party industrial devices. This integrated solution combines the SE4006P2 serial interface platform, the KJ3241X1-BK1 communication card, and the KJ4006X1-BD1 terminal block assembly to provide flexible, high-performance serial data exchange across complex automation environments.
Designed for mission-critical process industries, the module assembly supports multiple serial communication standards including RS232, RS422, and RS485. It enables seamless integration of PLCs, analyzers, flow computers, motor control systems, intelligent instruments, SCADA platforms, and legacy control equipment into the DeltaV architecture.
Its modular design, robust isolation protection, and advanced communication capabilities make it a preferred choice for facilities requiring dependable interoperability between modern control systems and field-level devices.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Emerson |
| Assembly Model | SE4006P2 + KJ3241X1-BK1 + KJ4006X1-BD1 |
| Product Type | Serial Interface Module Assembly |
| Platform | DeltaV S-Series |
| Interface Card | KJ3241X1-BK1 |
| Terminal Block | KJ4006X1-BD1 |
| Communication Ports | 2 Independent Serial Ports |
| Supported Standards | RS232, RS422, RS485 Half Duplex, RS485 Full Duplex |
| Protocol Support | Modbus RTU, Serial Device Integration |
| Data Sets Supported | 32 Total (16 per Port) |
| Electrical Isolation | Port-to-Port and Port-to-System Isolation |
| Baud Rates | 300–115200 bps |
| Data Bits | 7 or 8 |
| Parity Modes | None, Even, Odd |
| Stop Bits | 1 or 2 |
| Message Timeout | 100–25,500 ms |
| Retry Configuration | 0–255 Retries |
| LocalBus Power | 12 VDC |
| Current Consumption | Approx. 300 mA |
| Redundancy Support | Available |
| Status Diagnostics | Integrated Communication Diagnostics |
| Operating Temperature | -40°C to +70°C |
| Storage Temperature | -40°C to +85°C |
| Relative Humidity | 5%–95% Non-condensing |
| Shock Resistance | 10 g Half-Sine Wave |
| Vibration Resistance | Industrial Standard Compliance |
| EMC Protection | High Immunity EMI/RFI Design |
| Protection Rating | IP20 |
| Installation Method | DeltaV Carrier Mounted |
| Dimensions (H × W × D) | Approx. 263 mm × 138 mm × 88 mm |
| Weight | Approx. 2.2–2.5 kg |
Recommended Related Models
For complete DeltaV communication and process automation architectures, this assembly is commonly used together with:
| Model | Description |
|---|---|
| SE4036P2 | Redundant Serial Interface Module |
| KJ3241X1-BA1 | Alternative Serial Communication Card |
| KJ4006X1-BE1 | Extended Serial Interface Terminal Assembly |
| SE4003S2B1 | Analog Input Module |
| SE4003S2B6 | 16-Channel Analog Input Module |
| SE4005S2B4 | Analog Output Module |
| SE4003S7B1 | Discrete Input Module |
| SE4003S8B1 | Discrete Output Module |
| DeltaV PK Controller | Compact Process Controller |
| DeltaV MQ Controller | Advanced Control Processor |
These modules enable scalable communication, monitoring, and control architectures across industrial facilities.
