The Emerson SE4308T01 KL3102X1-BA1 Analog Output CHARM Module is engineered for safety-critical process automation where precision, reliability, and hazardous-area compliance are essential. Designed within the DeltaV Electronic Marshalling architecture, this module delivers stable 4–20 mA analog output signals with HART communication support, enabling accurate control of field devices in complex industrial environments.
Built for intrinsically safe applications, it ensures secure operation in hazardous zones while maintaining high signal integrity and seamless integration into Emerson’s distributed control ecosystem. Its compact CHARM design allows flexible system scaling, reduced wiring complexity, and faster engineering deployment.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Emerson |
| Model | SE4308T01 KL3102X1-BA1 |
| Product Type | Intrinsically Safe Analog Output CHARM |
| System Platform | DeltaV Electronic Marshalling (CHARM I/O) |
| Output Signal | 4–20 mA Analog Output |
| Communication | HART Protocol Support |
| Channels | 2 Output Channels |
| Power Supply | CHARM Bus + Field Loop Powered |
| Field Circuit Power | 24 V DC (system dependent) |
| CHARM Bus Power | 6.3 V DC |
| Installation Type | Plug-in CHARM Baseplate Module |
| Safety Rating | Intrinsically Safe (Hazardous Area Compatible) |
| Operating Temperature | -40°C to +70°C |
| Humidity Range | 5% to 95% non-condensing |
| Shock Resistance | 10 g mechanical shock tolerance |
| Dimensions (H × W × D) | Approx. 100 × 20 × 110 mm |
| Weight | Approx. 0.65 kg |
Engineering Compatibility & Recommended Related Modules
The SE4308T01 KL3102X1-BA1 performs best in DeltaV systems designed for electronic marshalling and high-integrity process control. It is commonly paired with:
- Emerson SE4307T01 KL3101X1-BA1 Analog Input CHARM
- Emerson SE4306T01 KL3104X1-BA1 Analog Input CHARM
- Emerson SE4053S2B11 Analog Input Plus Card
- Emerson SE4055S2B5 Analog Output Plus Card
- Emerson SE4059E0C0 I/O Interface Carrier
- Emerson SE4083S2B11 Redundant Input Module
These combinations help build a robust, scalable automation platform optimized for safety, efficiency, and lifecycle cost reduction.
Popular Emerson DeltaV CHARM & I/O Modules
Widely deployed Emerson modules in modern automation systems include:
- SE4053S2B11 High-Density Analog Input Module
- SE4055S2B5 Analog Output Plus Card
- SE4083S2B11 Redundant Analog Input Module
- SE4082S1T2B8 Digital Output Module
- SE4059E0C0 I/O Interface Carrier
- SE4307T01 KL3101X1-BA1 Input CHARM
- SE4306T01 KL3104X1-BA1 Input CHARM
- SE4308T01 KL3102X1-BA1 Output CHARM
These modules are trusted in high-risk industries where continuous operation and process safety are non-negotiable.
