The Emerson VE4001S3T2B2 is a DeltaV Series 2 discrete input module designed for high-reliability acquisition of 120 V AC digital field signals in industrial automation systems. It is commonly used to monitor ON/OFF status signals from switches, relays, limit devices, alarms, and control circuit contacts in power-intensive or legacy industrial environments.
This module is engineered for robust signal conditioning, electrical isolation, and stable operation under electrical noise conditions, making it suitable for demanding process industries where high-voltage discrete signals are still widely used.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Emerson |
| Model | VE4001S3T2B2 |
| Product Type | Discrete Input Module (DI) |
| System Platform | DeltaV Series 2 I/O |
| Input Channels | 8 channels |
| Input Type | 120 V AC digital input |
| Signal Type | Dry contact / AC status signals |
| Input Voltage Range | 90–132 V AC (typical industrial range) |
| Frequency | 50/60 Hz |
| Response Time | ≤ 10 ms (typical) |
| Isolation | Channel-to-system galvanic isolation |
| Diagnostics | Channel status and fault detection |
| Wiring Type | Fused termination interface |
| Mounting Method | DeltaV I/O carrier mounted |
| Operating Temperature | -40°C to +70°C |
| Humidity Range | 5%–95% non-condensing |
| EMC Protection | Industrial noise immunity design |
Physical Dimensions & Weight
| Parameter | Specification |
|---|---|
| Dimensions (H × W × D) | 105 × 125 × 42 mm |
| Weight | Approx. 0.30–0.45 kg |
Recommended Related Models
The VE4001S3T2B2 is commonly used in DeltaV systems together with:
- Emerson VE3006 MD Plus Controller Module
- Emerson VE3008 MQ Controller Module
- Emerson VE4003S2B1 Analog Input Module
- Emerson VE4005S2B1 Analog Output Module
- Emerson VE4033S2B1 Redundant I/O Module
- Emerson VE4001S3T1B2 120 V AC DI Module Variant
- Emerson VE4001S2T2B1 24 V DC DI Module
- Emerson VE4001S2T2B4 Analog Output Module
- Emerson KJ3241X1-BA1 Serial Interface Module
- Emerson SE4055S2B5 Analog Output Card
