The Emerson VE4001S4T1B1 is a DeltaV Series 2 discrete input module designed for reliable acquisition of high-voltage AC digital signals in industrial automation systems. It is commonly used to monitor ON/OFF status from field devices such as relays, switches, limit contacts, breaker auxiliaries, and alarm circuits operating in 230 V AC environments.
Built for harsh electrical conditions, this module provides strong isolation, stable signal detection, and robust diagnostics, making it suitable for power-intensive industrial applications where high-voltage discrete signals are still widely used.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Emerson |
| Model | VE4001S4T1B1 |
| Product Type | Discrete Input Module (DI) |
| System Platform | DeltaV Series 2 I/O |
| Input Channels | 8 channels |
| Input Type | 230 V AC digital input |
| Signal Type | AC dry contact / powered status signals |
| Input Voltage Range | 180–264 V AC (typical industrial range) |
| Frequency | 50/60 Hz |
| Response Time | ≤ 10 ms (typical) |
| Isolation | Channel-to-system galvanic isolation |
| Diagnostics | Channel status and fault detection |
| Wiring Type | Industrial terminal interface |
| Mounting Method | DeltaV I/O carrier mounted |
| Operating Temperature | -40°C to +70°C |
| Humidity Range | 5%–95% non-condensing |
| EMC Protection | Industrial-grade noise immunity design |
Physical Dimensions & Weight
| Parameter | Specification |
|---|---|
| Dimensions (H × W × D) | 105 × 125 × 42 mm |
| Weight | Approx. 0.20–0.40 kg |
