Introduction

The Allen Bradley 2711P-B7C22A9P PanelView Plus 7 Operator Interface delivers a reliable and efficient human-machine interface solution for advanced industrial environments. Combining responsive touch and keypad input with strong network integration, it provides operators with clear visibility and control over complex processes. Its durable construction and modern communication capabilities make it a trusted choice for both new automation systems and upgrades to existing installations.

Technical Specifications

Technical Parameter	Specification
Product Model	2711P-B7C22A9P
Product Series	PanelView Plus 7
Display Size	6.5-inch TFT Color Display
Display Resolution	640 × 480 VGA
Input Method	Touchscreen + Keypad
Dimensions (W × H × D)	285 × 179 × 69.6 mm
Weight	1.47 kg (3.25 lb)
Input Voltage	100–240 VAC
Power Consumption	105 VA
Communication Interfaces	Ethernet, USB
Memory	Non-volatile Flash Memory
Operating Temperature	0°C to 55°C
Storage Temperature	-25°C to 70°C
Relative Humidity	5% to 95% Non-condensing
Mounting Method	Panel Mount
Protection Rating	IP66 / NEMA 4X
Certifications	CE, UL, cUL

Applications

The Allen Bradley 2711P-B7C22A9P PanelView Plus 7 Operator Interface is designed for modern industrial automation systems requiring high-speed visualization, secure operator control, and reliable communication with PLC networks.

Typical applications include:

Discrete manufacturing systems
Packaging and bottling production lines
Automotive assembly operations
Process control systems
Energy and utility monitoring
Pharmaceutical and food production environments
SCADA visualization terminals
OEM machine interface solutions

Advantages

High-performance visualization: Smooth graphical interface for real-time process monitoring
Dual input operation: Supports both touchscreen and keypad for flexible control
Industrial connectivity: Seamless integration with ControlLogix and CompactLogix systems
Robust communication: Ethernet-based architecture for fast and stable data exchange
Enhanced operator efficiency: Reduces response time through intuitive navigation
Secure system access: Multi-level user security control for industrial environments
Built for harsh environments: Designed for continuous operation in demanding conditions

Technical FAQs

Which PLC systems are compatible with this model?
It is primarily used with Allen Bradley ControlLogix and CompactLogix controllers via Ethernet/IP communication.
Does the terminal support remote access?
Yes, it supports remote monitoring and control depending on system configuration and security settings.
Can it display real-time process data?
Yes, it supports dynamic tag-based visualization for live industrial data.
Is application memory retained during power loss?
Yes, all runtime applications are stored in non-volatile memory.
Does it support alarm handling?
Yes, alarms can be displayed, acknowledged, and logged within the HMI system.
Can multiple screens be configured?
Yes, multiple operator screens can be created for different process functions.
How is system communication monitored?
Built-in diagnostics provide Ethernet and controller communication status.
Is user access control available?
Yes, multi-level security permissions can be configured for operators and engineers.
Can firmware be updated?
Yes, firmware updates are supported through Rockwell-approved tools and procedures.
Is it suitable for continuous operation?
Yes, it is engineered for 24/7 industrial use under recommended environmental conditions.
