The Bently Nevada 330101-30-63-10-02-00 Proximity Probe is a high-performance component of the trusted 3300 XL 8 mm Proximity Transducer System, designed to deliver accurate, non-contact measurement of shaft vibration, axial position, and displacement in critical rotating machinery. Engineered for long-term reliability, this probe supports continuous condition monitoring and machinery protection programs across a wide range of industrial environments.
Its advanced eddy current sensing technology provides stable and repeatable measurements, helping maintenance teams detect potential equipment issues before they develop into costly failures. The probe is widely utilized in applications where operational uptime, equipment safety, and maintenance efficiency are top priorities.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Bently Nevada |
| Model Number | 330101-30-63-10-02-00 |
| Product Type | Proximity Probe |
| Series | 3300 XL 8 mm Proximity Transducer System |
| Measurement Technology | Eddy Current Sensing |
| Probe Diameter | 8 mm |
| Thread Type | 3/8-24 UNF |
| Unthreaded Length Option | 3.0 in |
| Case Length Option | 6.3 in |
| System Length | 1.0 m |
| Connector Type | Miniature ClickLoc Connector |
| Agency Approval | Standard Industrial Approval |
| Housing Material | Stainless Steel |
| Cable Type | Shielded Coaxial Cable |
| Measurement Functions | Shaft Vibration, Position, and Displacement |
| System Compatibility | Bently Nevada 3300 XL Systems |
Dimensions & Weight
| Item | Specification |
|---|---|
| Probe Diameter | 8 mm |
| Unthreaded Length | 3.0 in (76.2 mm) |
| Case Length | 6.3 in (160.0 mm) |
| Total System Length | 1.0 m |
| Approximate Weight | 0.35–0.55 kg |
| Housing Material | Stainless Steel |
