The Bently Nevada 330102-40-70-10-02-00 is part of the 3300 XL 8 mm proximity probe system, designed for non-contact measurement of shaft vibration, displacement, and position in rotating machinery.
It is used as a key component in a complete proximity transducer chain with a Proximitor sensor and extension cable. This configuration is widely applied in industrial condition monitoring systems for turbines, compressors, pumps, and generators where continuous reliability and stable measurement performance are required.
The “40-70” configuration typically indicates an extended mechanical geometry variant within the 3300 XL ordering structure, selected based on mounting depth and installation requirements.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Bently Nevada |
| Model Number | 330102-40-70-10-02-00 |
| Product Type | Proximity Probe |
| Series | 3300 XL 8 mm System |
| Measurement Principle | Eddy Current Non-contact Sensing |
| Probe Diameter | 8 mm |
| Thread Type | 3/8-24 UNF |
| Probe Construction | Armored design |
| Connector Type | Miniature ClickLoc coaxial connector |
| System Requirement | Requires Proximitor sensor + extension cable |
| Application | Vibration, displacement, position monitoring |
Dimensions & Weight
| Item | Specification |
|---|---|
| Probe Diameter | 8 mm |
| Unthreaded Length | 4.0 in (code 40) |
| Case Length | 7.0 in (code 70) |
| System Length | 1.0 m class configuration |
| Net Weight | Approx. 0.30–0.35 kg |
| Shipping Weight | Approx. 1.0–1.5 kg |
| Packaging Type | Industrial protective carton |
