The Bently Nevada 330102-60-90-10-02-05 is part of the 3300 XL 8 mm proximity probe system, designed for non-contact measurement of shaft vibration, displacement, and position in rotating machinery.
It is typically used as a component of a complete proximity transducer chain with a Proximitor sensor and extension cable. This configuration is widely applied in turbines, compressors, pumps, and generators where continuous condition monitoring and high measurement stability are required.
The “60-90” configuration generally indicates an extended mechanical installation geometry within the 3300 XL ordering structure, often used where deeper probe insertion or specific mounting constraints are required.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | Bently Nevada |
| Model Number | 330102-60-90-10-02-05 |
| Product Type | Proximity Probe |
| Series | 3300 XL 8 mm System |
| Measurement Principle | Eddy Current Non-contact Sensing |
| Probe Diameter | 8 mm |
| Thread Type | 3/8-24 UNF |
| Probe Construction | Armored design |
| Connector Type | Miniature ClickLoc coaxial connector |
| System Requirement | Requires Proximitor sensor + extension cable |
| Application | Vibration, displacement, position monitoring |
Dimensions & Weight
| Item | Specification |
|---|---|
| Probe Diameter | 8 mm |
| Unthreaded Length | 6.0 in (code 60) |
| Case Length | 9.0 in (code 90) |
| Total System Length | 1.0 m class configuration |
| Net Weight | Approx. 0.32–0.35 kg |
| Shipping Weight | Approx. 1.3–2.0 kg |
| Packaging Type | Industrial protective carton |
The 3300 XL ordering structure defines mechanical geometry via codes; exact interpretation should always follow official Bently Nevada ordering documentation for engineering use.
