Brand:Allen Bradley PLC Item No.:80190-480-01-R Product Origin:USA Product Dimensions:180 x 25 x 150 mm Product Weight:0.42 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Allen Bradley 80190-480-01-R Drive Control Board is a critical internal module used in PowerFlex 7000 drive systems. It acts as the central intelligence layer responsible for executing motor control logic, coordinating system operations, and maintaining stable drive performance. Designed for high-demand industrial environments, it plays a key role in ensuring precise and reliable operation of medium-voltage motor control systems where downtime is costly and performance consistency is essential.
Technical Specifications
Item
Specification
Product Type
Drive Control Board
Compatible System
PowerFlex 7000
Function
Motor control & system coordination
Redundancy Support
Yes (dual-board configuration)
Mounting
Internal drive chassis slot
Dimensions
180 × 25 × 150 mm
Weight
0.42 kg
Operating Role
Control logic processing module
Application Level
Medium-voltage industrial drive systems
Maintenance Type
Board-level replacement
Recommended Related Models
Model Number
Product Name
80190-450-01-R
PowerFlex 7000 Drive Interface Board
80190-460-02-R
PowerFlex 7000 Control Processor Module
80190-470-01-R
PowerFlex 7000 System Control Card
80190-490-01-R
PowerFlex 7000 Redundant Control Board
Popular Related Models
Model Number
Product Name
80190-430-01-R
PowerFlex 7000 Auxiliary Control Board
80190-440-01-R
PowerFlex 7000 Communication Interface Board
80190-450-02-R
PowerFlex 7000 Drive System Module
80190-500-01-R
PowerFlex 7000 Advanced Control Unit
Applications
• PowerFlex 7000 drive system control
Used as a core control module in medium-voltage industrial drive architectures.
• Motor drive coordination systems
Manages synchronized operation of industrial motors within complex automation setups.
• Heavy-duty industrial process control
Applied in oil & gas, power generation, and large-scale manufacturing environments.
• Redundant drive control configurations
Supports dual-board redundancy for high-reliability critical systems.
• Industrial retrofit and drive repair systems
Used for replacement and maintenance of legacy drive control platforms.
Key Advantages
• Central control intelligence for drive systems
Executes motor control algorithms and system-level coordination functions.
• High reliability in demanding industrial environments
Designed for continuous operation in harsh electrical and thermal conditions.
• Supports redundant control architecture
Enables failover operation to improve system uptime and fault tolerance.
• Strong integration with PowerFlex 7000 platforms
Ensures compatibility within Rockwell Automation drive ecosystems.
• Modular service and maintenance design
Allows replacement at board level without full drive system overhaul.
• Stable signal processing for motor regulation
Maintains accurate control of power conversion and drive output behavior.
Technical FAQs
1. What is the main function of the 80190-480-01-R board?
It serves as the primary control board in PowerFlex 7000 drive systems, managing motor control and system coordination.
2. Which drive series is it used with?
It is mainly used in the PowerFlex 7000 medium-voltage drive platform.
3. Is this a power board or a control board?
It is a drive control board, not a power conversion module.
4. Can it operate independently outside the drive system?
No, it must operate inside a compatible drive chassis system.
5. Does it support redundancy?
Yes, it supports dual-board redundant configurations for high availability systems.
6. What happens if the main board fails?
In redundant setups, the system can automatically switch control to a secondary board.
7. Is it responsible for motor power output?
It controls the logic and regulation, but not direct power switching hardware.
8. Can it be hot-swapped during operation?
No, replacement typically requires system shutdown for safety.
9. What industries commonly use this board?
It is used in heavy industrial sectors such as energy, oil & gas, and manufacturing.
10. Is this a current or legacy product?
It is generally considered a legacy or specialized service component depending on system version.
