Brand:Schneider PLC Item No.:TM5SAO2L Product Origin:France Product Dimensions:99 x 12.5 x 75 mm Product Weight:0.025 kg Payment:T/T, Western Union, Credit Card Goods_stock:15 Shipping Port:Xiamen, China Lead Time:1-3 Days Condition:Brand New And Original Warranty:1 Year Certificate:COO
The Schneider TM5SAO2L is a compact analog output module designed for the Modicon TM5 distributed I/O system, providing two high-precision output channels for voltage and current signal generation in industrial automation applications.
Engineered for machine control and process regulation, it enables precise control of actuators, drives, and proportional devices through stable analog signals. Its ultra-slim design and modular architecture make it ideal for space-constrained control cabinets and scalable automation systems used across manufacturing, process industries, and OEM machinery.
Technical Specifications
Parameter
Description
Model
Schneider TM5SAO2L
Product Type
Analog Output Module
Series
Modicon TM5
Number of Channels
2
Output Types
±10 V / 0–20 mA
Resolution
12-bit + sign
System Compatibility
Modicon LMC058 / M258
Installation Type
DIN rail mounted
Communication
TM5 bus system
Dimensions
99 × 12.5 × 75 mm
Weight
0.025 kg
Recommended Related Models
Model
Product Name
Schneider TM5SAO4L
4-channel Analog Output Module
Schneider TM5SAI2L
2-channel Analog Input Module
Schneider TM5ACBM11
TM5 Bus Base Module
Schneider BMXDDO3202K
Modicon Digital Output Module
Popular Related Models
Model
Product Name
Schneider BMXAMI0810
Analog Input Module (Modicon X80)
Schneider BMXDAI1604
Digital Input Module
Schneider BMXP342020
M340 PLC Processor Module
Schneider ATV320U06N4B
Variable Speed Drive
Applications
• PLC-based analog signal output control in industrial automation systems
Provides precise analog voltage and current signals for actuators, drives, and process control elements in automated machinery.
• Modicon TM5 distributed I/O systems in machine control architecture
Used as part of modular expansion systems to extend analog output capability in compact PLC setups.
• Process control regulation in manufacturing and production lines
Enables smooth control of valves, actuators, and variable devices through analog command signals.
• Motion and drive system signal interfacing in OEM equipment
Supports analog reference signals for speed, torque, and positioning control in machine automation.
• HVAC and environmental control systems
Used for regulating dampers, fans, and proportional control elements via analog outputs.
• Industrial test benches and simulation systems
Provides stable analog signal generation for testing and calibration of control devices.
Key Advantages
• Compact ultra-slim design for high-density control cabinets
At only 12.5 mm width, it allows efficient use of DIN rail space in modular automation panels.
• Dual-channel analog output capability
Delivers two independent outputs supporting voltage and current modes for flexible system design.
• High-resolution signal conversion for stable control performance
Ensures smooth and precise analog signal generation for sensitive industrial applications.
• Seamless integration with Modicon TM5 architecture
Designed specifically for Schneider Electric distributed I/O ecosystems.
• Fast response performance for dynamic process control
Supports real-time signal updates for responsive automation behavior.
• Lightweight construction for modular expansion systems
Facilitates easy installation and system scalability without adding mechanical load.
Technical FAQs
Q1: What is the main function of this module?
A: It provides two analog output channels for controlling industrial devices via voltage or current signals.
Q2: What systems is it compatible with?
A: It is designed for Schneider Modicon TM5 systems, typically used with LMC058 and M258 controllers.
Q3: What output types does it support?
A: It supports ±10 V voltage output and 0–20 mA current output.
Q4: How many channels are available?
A: It has 2 analog output channels.
Q5: Is it suitable for precision control applications?
A: Yes, it provides 12-bit resolution for stable signal control.
Q6: Can it be used in distributed I/O systems?
A: Yes, it is designed for modular distributed automation architectures.
Q7: What type of installation is required?
A: It is DIN rail mounted as part of the TM5 system.
Q8: Is it suitable for OEM machinery?
A: Yes, it is widely used in compact OEM automation systems.
Q9: Does it support both voltage and current outputs simultaneously?
A: Each channel can be configured for either voltage or current output mode.
Q10: Is it designed for continuous operation?
A: Yes, it is built for industrial 24/7 operating environments.
